13
www.infraredsauna.com
INSTALLING WALL LOCKS
9
INSTALLING GLASS PORTION OF ROOF
10
1. Place the glass roof portion on the front roof guides. Be sure that it is pushed firmly back against the wood roof portion.
2. Latch the buckle on the right side of the sauna to secure glass roof in place.
1. The side walls must be secured to the back wall and
wood roof piece using the aached eye hooks.
2. Screw in one of the eye hooks between the le side
wall and back wall and one between the right side
wall and back wall.
A. This part comes pre-assembled to the side walls.
You must unscrew one side so that you can swing it
around to aach to the back wall.
B. Aach the eye hook so that it is screwed into side
walls and the wood roof piece.
THIS STEP IS VERY IMPORTANT.
PLEASE DO NOT OMIT THIS STEP.
Pre-drilled holes are not necessary for this step.
To Next Page
