ClearOne CONVERGE PRO 2 - Connect via CP2 GPIO or USB Expander

Quick-Start Guide
7
By serial connection via a CP2 GPIO or USB Expander, using a serial
cable attached to the Phoenix Euroblock Adapter accessory:
Beamforming Mic Array 2
CONVERGE Pro 2
CP2 GPIO
Expander
Rear Panel
Touch Panel Controller
DB9 RS232
female to male cable
(50’, 100’, or 50’+100’)
Phoenix Euroblock to
DB9 RS232 adapter
CAT6 Ethernet cable
(50’, 100’, 150’, or 200’)
Legend
P-link
P-link
Power Options:
A. Power Adapter
B. PoE Injector
C. PoE Ethernet
D. Power over P-link
