CleaverBrooks Model 4 User Manual

Model 4
1500 - 6000 MBTU/hr
Rev. 03-08
Section B2-25
Table B2-20. Gas line capacity - Schedule 40 metallic pipe
Pipe Siz e
Nominal
1/2 " 3/4" 1" 1-1/4" 1-1/2 " 2" 2-1/2" 3" 4"
Ac t ual
I.D.
0.622 0.824 1.049" 1.380" 1. 610" 2.067" 2.469" 3.068" 4.026"
Length
in feet
**Maximum Capacity in Cubic Feet of Gas per Hour (cfh)
10
3,190 6,430 11,800 24,200 36,200 69,700 111,000 196,000 401,000
20
2,250 4,550 8,320 17,100 25,600 49,300 78,600 139,000 283,000
30
1,840 3,720 6,790 14,000 20,900 40,300 64,200 113,000 231,000
40
1,590 3,220 5,880 12,100 18,100 34,900 55,600 98,200 200,000
50
1,430 2,880 5,260 10,800 16,200 31,200 49,700 87,900 179,000
60
1,300 2,630 4,800 9,860 14,800 28,500 45,400 80,200 164,000
70
1,200 2,430 4,450 9,130 13,700 26,400 42,000 74,300 151,000
80
1,150 2,330 4,260 8,540 12,800 24,700 39,300 69,500 142,000
90
1,060 2,150 3,920 8,050 12,100 23,200 37,000 65,500 134,000
100
979 1,980 3,620 7,430 11,100 21,400 34,200 60,400 123,000
125
876 1,770 3,240 6,640 9,950 19,200 30,600 54,000 110,000
150
786 1,590 2,910 5,960 8,940 17,200 27,400 48,500 98,900
175
728 1,470 2,690 5,520 8,270 15,900 25,400 44,900 91,600
200
673 1,360 2,490 5,100 7,650 14,700 23,500 41,500 84,700
500
384 802 1,510 3,100 4,650 8,950 14,300 25,200 51,500
1000
264 551 1,040 2,130 3,200 6,150 9,810 17,300 35,400
1500
212 443 834 1,710 2,570 4,940 7,880 13,900 28,400
**Fuel: Natural Gas
**Inlet Pressure: 5.0 psi
**Pressure Drop: 3.5 psi
**Specific Gravity: 0.60
