en03d441.fm, 07.04.2011 PL12EN-1001 2011-04 27
Programming
3
3.2.1 Basic Application Builder Parameters
In the Basic Application Builder some parameters are not programmable and are also set to default values.
These values are located in the Standard Application Builder. However, if the parameters are changed
using the Standard Application Builder, then the Basic Application Builder does not reset them back to the
default values.
3.2.2 Advanced Parameter Default Values
If an Application with more than two stages is required, or if a different Fastening Strategy has previously
been selected for the Application than described above, the Standard Application Builder must be used.
From the Basic Application Builder, the Auto Program feature is available by pressing <Auto Program> only
when a tool is connected to the controller and if the application is not already programmed. <Auto Program>
is disabled if there is no tool or if the application is programmed or if Angle Control/Torque Monitoring is
selected.
The Auto Program feature accepts the Stage 2 target torque. Pressing <Cancel> exits the auto program
screen without saving changes. Pressing <OK> causes the auto calculations to be done and the results are
displayed on the basic screen.
From the Basic Application Builder, the user can copy the parameters of an application to one or more other
applications by pressing <Copy>. From this dialog box, the user can specify the source and target tool and
Parameter Name Range Typical
Fastening Strategy Torque Control/Angle Monitor Torque Control/Angle Monitor
Fastening Strategy Angle Control/Torque Monitor Angle Control/Torque Monitor
Trigger Torque [Nm] 0 to Tool Max 10% of Turnoff Torque
Turnoff Torque Stage 1 [Nm] 0 to Tool Max As appropriate
Threshold Torque [Nm] Turnoff 1 to Tool Max 50% of Turnoff Torque
Torque Low Limit [Nm] -Tool Max* to Tool Max 90% of Turnoff Torque
Turnoff Torque Stage 2 [Nm] Low Limit to Tool Max As appropriate
Torque High Limit [Nm] Turnoff to 1.2 TQ-Cal. value 110% of Turnoff Torque
Angle Low Limit [Deg] 0 to 9999 90% of Turnoff Angle
Turnoff Angle [Deg] Low Limit to 9999 As appropriate
Angle High Limit [Deg] Turnoff to 9999 110% of Turnoff Angle
Speed Stage 1 [RPM] 0 to Tool Max 80% of Tool Max
Speed Stage 2 [RPM] 0 to Tool Max 50
Backoff Speed 0 to Tool Max 50% of Tool Max
NOTE
Negative values may be entered by preceding the value with a dash "-".
Parameter Name Stage 1 Stage 2
Start delay time [mS] 0 0
Start spike time [mS] 0 0
Max. Fastening time [mS] 10000 10000
End delay time [mS] 0 0 (30 with Auto Program)
Torque Filter Factor 1 4 (1 with Auto Program)
