26 PL12EN-1001 2011-04 en03d441.fm, 07.04.2011
Programming
3
<Archive>
Chronological History are viewable from this screen. Data can be erased as well.
<Diagnostics>
Contains screens to determine if the system is functioning properly.
<Utilities>
Contains functions for upgrading or changing the system software. From the Utilities the user can update
the mPro400GC application software, or install a new firmware version in the Tightening Module.
<Administration>
The user can load, save and configure system information. Administration functions include loading and
saving the system configuration, setting date and time, setting password protection, and printing the system
configuration, and selecting the application software language (English and German). From Administration
> Counter screen, the user may view or reset any of the available counters.
3.2 Basic
Allows the user to select a typical two-stage rundown where the first stage is a high speed rundown and the
second stage is a different speed rundown that controls on either torque or angle.
Fastening Strategies Torque Control/Angle Monitoring (SEQ 11/SEQ 30) or Angle Control/Torque Monitor-
ing (SEQ 11/SEQ 50) are selectable from the drop-down list in the upper right hand corner of the screen.
Once a Strategy is selected, the appropriate parameters will be displayed for programming.
Basic Parameters for Torque Control/Angle Monitor:
• Trigger Torque [Nm] Torque to start collecting oscilloscope data.
• Turnoff Torque Stage 1 [Nm] Torque to change from stage 1 to stage 2.
• Threshold Torque [Nm] Torque to begin counting angle in stage 2.
• Torque Low Limit [Nm] Minimum acceptable torque.
• Turnoff Torque Stage 2 [Nm] Torque to turnoff the tool.
• Torque High Limit [Nm] Maximum acceptable torque.
• Angle Low Limit [Deg] Minimum acceptable angle.
• Angle High Limit [Deg] Maximum acceptable angle.
Basic Parameters for Angle Control/Torque Monitor:
• Turnoff Angle [Deg] Angle to turnoff the tool.
• The rest of the Parameters are the same as Torque Control/Angle Monitor except Turnoff Torque Stage
2 is eliminated.
Following are the acceptable ranges for each Parameter.
