Programming
3
3.4.2 Inputs
Each of the physical inputs 0–7 can be programmed to have one of the following definitions:
3.4.3 Outputs
Not Used Unused
Tool Enable When active, allows the tool to run in conjunction with Tool Start.
Tool Start Starts the tool.
External Tool Start Allows external input to control the start of the tool.
Tool Reverse When active, causes the tool to run in the counterclockwise direction using
the Backoff strategy.
External Tool Reverse Allows external input to control tool running in the counterclockwise direction.
Application Select 0 Application Selects 0–7 are used to select Applications 1–99 using a binary
count of 1–99 where Application Select 0 is the least significant bit. When
Linking is activated, the Tightening Group is selected with these inputs.
Application Select 1
Application Select 2
Application Select 3
Application Select 4
Application Select 5
Application Select 6
Application Select 7
Reset Linking When active, Linking (batch counting) is reset to position one.
Not Used Unused
OK Active if Torque/Angle/Yield are within programmed limits.
NOK Active if Torque/Angle/Yield are outside limits or some other error has
occurred.
Cycle Complete Active when a rundown has ended and there are status outputs to report
Linking Complete Active when rundowns of all positions of the selected batch group are com-
plete
Linking OK Active if all positions of Linking were OK
Linking NOK Active if one or more positions of Linking were NOK
Confirm App. Sel 0 Confirm application Selects 0–7 are used to indicate the currently selected
applications 1–99 using a binary count where Application Select 0 is the least
significant bit.
Confirm App. Sel 1
Confirm App. Sel 2
Confirm App. Sel 3
Confirm App. Sel 4
Confirm App. Sel 5
Confirm App. Sel 6
Confirm App. Sel 7
