Clesana C1 - Install the L-Adapter; Screw the L-Adapter on the floor; Screw the L-Adapter to the wall

21/3220/32
8. Install the L-Adapter
8.1. Screw the L-Adapter on the oor
ø8.1
ø4.4
3
Fig. 3: 
No. Tools and consumables
1 Screwdriver
5 

1. Align the L-Adapter to the wall.
2. 
8.2. Screw the L-Adapter to the wall
143 mm
145 mm
145 mm
294 mm
ø 4.5 mm
Fig. 4: Bores for screwing on the wall


No. Tools and consumables
1 Wood drill Ø 4.5 mm
1 Screwdriver
3 Wood screw half-round head/plate head Ø 4.5 mm

1. Bore 3 holes in the wall according to
the template.
2. Choose the length of the wood screws

mm.
3. 
bore holes.
4. Screw 3 wood screws from behind


5. 
lip of the L-Adapter with the wall.
27
