– up to 8 m: 10 mm²
– from 8 m: 16 mm²
X
on the power supply.
X Do not clamp or excessively bend the cables.
2.4.3 Component damage due to short circuit
Reversing the polarity of the power cable can damage the electrical components. A
X Ensure the correct polarity of the power cable before switching on the power
supply.
2.4.4 Moving parts
X Keep the surroundings of the toilet free of objects.
2.4.5 Water damages
dismantled. Faulty sealing of the water line can result in water damages in the vehicle.
X
X
X Ensure correct sealing of the L-Adapter.
2.4.6 Health hazards from contaminated water
X
e.g. on a manifold or a T-piece.
X Ensure that the shut-down water line does not allow any standing water in the line.
3. Delivery scope
No. Part
1 Base body Clesana C1
1 L-Adapter or round base
1 Control panel with cable
2
1
1
1
1
Barrier foil liner not included in the scope of delivery.
X
4.
No. Tools
1 Screwdriver Torx TX20
1 Wood drill Ø 4.5 mm
1
Wood drill Ø 16 mm
1
1 Press tool for cable lug and connector
No. Installaon material
1
—
— Ring cable lug
— Cable strap
3 Wood screw half-round head/plate head Ø 4.5 mm
4
Wood screw half-round head/plate head Ø 4.5 mm
5
