Clesana C1 - Wall mounting

27/3226/32
4. 
5. 

10.2. Wall mounng
128 mm
85 mm
ø 4.5 mm
Hole in the wall
min. ø 16 mm
4 mm
41.6 mm
Fig. 8: Measurements of the wall-mounted housing

the housing yourself. The design data (CAD and design drawings) are available in the
dealer area .
No. Tools and consumables
1 Wood drill Ø 16 mm
1 Screwdriver
4 Wood screw half-round head/plate head Ø 4.5 mm

1. 
following points:
– The display is clearly legible.
– The control panel can be easily operated.
– The distances between the control panel and the L-Adapter is smaller than the

2. 
3. Lay the cable ends from L-Adapter or round base to the control panel.
4. 
5. 
6. 
