Introduction
1 - 4 External Locator - Top View with LCD Panel Open
1.Introduction
External Locator - Top View with LCD Panel Open
Figure 1
Top View
1. PC Camera
Or
(Factory Option)
Windows Hello
Camera
2. *Camera LED
*When the PC
camera is in use,
the LED will be
illuminated in
white.
3. Built-In Array
Microphone
4. Display
5. Keyboard
6. Touchpad &
Buttons
5
2 1 3
4
3
6
