Introduction
Mainboard Overview - Bottom (Connectors) 1 - 11
1.Introduction
Mainboard Overview - Bottom (Connectors)
Figure 10
Mainboard Bottom
Connectors
1. HDMI-Out Port
2. Display Port
3. DC-In Jack
4. VGA Fan Cable
Connector
5. 3G / SSD
Connector
6. CMOS Battery
7. SSD Connector
8. CPU Fan Cable
Connector
1
2
3
4
2
6
5
7
8
