Introduction
Mainboard Overview - Bottom (Connectors) 1 - 11
1.Introduction
Mainboard Overview - Bottom (Connectors)
Figure 10
Mainboard Bottom
Connectors
1. HDD Connector
2. Fan Cable
Connector
3. Multi-in-1 Card
Reader
4. HDMI-Out Port
5. RJ-45 LAN Jack
6. External Monitor
Port
7. DC-In Jack
8. Microphone Cable
Connector
9. LVDS Cable
Connector
10.Battery Connector
11. ODD Cable
Connector
1
2
4
5
6
7
8
9
3
11
10
