Disassembly
Removing the 3G Module 2 - 13
2.Disassembly
Removing the 3G Module
Figure 9
3G Module Removal
a. Disconnect the cables
and remove the screw.
b. The module will pop-up.
c. Remove the 3G module.
Note: Make sure you
reconnect the antenna
cable to socket.
1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - 8).
2. Carefully disconnect the cables
& , and then remove the screw (Figure 9a).
3. The 3G module will pop-up, and you can remove it from the computer (Figure 9b).
1
2
3
4
b.
a.
3
2
4
4
1
c.

4. 3G Module
•1 Screw
