Clevo W25CSV series User Manual

Disassembly
2 - 8 Removing the System Memory (RAM)
2.Disassembly
Removing the System Memory (RAM)
The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting
DDR3L Up to 1600 MHz. The main memory can be expanded up to 16GB. The SO-DIMM modules supported are
1024MB and 2048MB DDR3L Modules. The total memory size is automatically detected by the POST routine once you
turn on your computer.
Memory Upgrade Process
1. Turn off the computer, turn it over to remove the battery (page 2 - 5).
2. Locate the component bay cover and remove screws - .
3. Carefully remove the component bay cover .
1
5
6
b.
4
2
6
a.
1
3
5

6. Component Bay Cov-
er
•5 Screws
Figure 4
RAM Module
Removal
a. Remove the screws.
b. Remove the cover.
