1
3
4
2
5
Powered USB Port
Note that the powered USB 3.2 (Type A) port is not operational under DOS and does not support wake
on USB. The powered USB 3.2 ( ) port can supply power (for charging devices only, not for op-
erating devices) when the system is off but still powered by the AC/DC adapter plugged into a working
outlet, or powered by the battery with a capacity level above 20% (this may not work with certain de-
vices). Toggle power to this port by using Fn + power button.
USB Ports
USB 3.2 (Gen 2) ports are capable of 10Gbps (SuperSpeed USB 10Gbps) and USB 3.2 Gen 2x2 ports
have a throughput of 20 Gbps (SuperSpeed USB 20Gbps).
There are three USB 3.2 Gen 2 (Type A) ports on this computer model (including the powered
USB port). In addition there is a Type C USB 3.2 Gen 2*2 port capable of 20Gbps SuperSpeed
and 1 DisplayPort 1.4 over USB 3.2 Gen 2 (Type-C).
The Type C ports are the smaller sized USB ports, and the larger USB Type A ports are denoted by
their blue color.
The DisplayPort 1.4 over USB 3.2 Gen 2 (Type-C) combines full DisplayPort A/V performance with Su-
perSpeed USB in a single connector.
