CLIMATEMASTER WATER-SOURCE HEAT PUMPS
6
ClimateMaster Water-Source Heat Pumps
Tranquility 16 (TC) Series
Rev.: 25 July, 2017
TC Series 006 009 012 015 018 024 030 036 042 048 060
Compressor (1 Each)
Rotary Scroll
Factory Charge HFC-410A - kg
0.48 0.52 .65 0.91 1.22 1.22 1.36 1.42 1.98 2.10 2.32
PSC Fan Motor & Blower
Fan Motor Type/Speeds
PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3
Fan Motor (Watts)
30 75 75 124 124 187 560 373 560 560 746
Blower Wheel Size (Dia x w) mm
127 x 127 127 x 127 152 x 127 203 x 178 229 x 178 229 x 203 254 x 254 279 x 254
Water Connection Size
FPT
1/2” 1/2" 1/2” 1/2" 1/2" 3/4" 3/4" 3/4" 3/4" 1" 1"
Coax Volume (liters)
.47 .54 .63 1.08 1.70 1.08 1.22 1.22 3.37 2.79 3.55
Vertical
Air Coil Dimensions (H x W) mm
254 x 381 254x381 254 x 381 508 x 438 508 x 438 508 x 438 508 x 438 610 x 552 610 x 552 610 x 718 610 x 718
Filter Standard - 25.4mm
Throwaway mm
254 x 457 254x457 254 x 457 508 x 508 508 x 508 508 x 508 508 x 508 610 x 610 610 x 610
1-356 x 610,
1- 457 x 610
1-356 x 610,
1- 457 x 610
Weight - Operating kg
47 48 52 69 72 86 89 92 99 119 126
Weight - Packaged kg
51 52 56 72 74 88 92 95 102 123 129
Horizontal
Air Coil Dimensions (H x W) mm
254 x 381 254 x 381 254 x 381 406 x 559 406 x 559 406 x 559 406 x 559 508 x 635 508 x 635 508 x 889 508 x 889
Filter Standard - 25.4mm
Throwaway mm
254 x 457 254 x 457 254 x 457 406 x 635 406 x 635 457 x 635 457 x 635
508 x 711 or
(2) 508 x 356
508 x 711 or
(2) 508 x 356
1-508 x 610,
1-508 x 356
1-508 x 610,
1-508 x 356
Weight - Operating kg
47 47 52 69 72 86 89 92 99 119 138
Weight - Packaged kg
51 52 56 72 74 88 92 95 102 123 141
Notes:
All units have dual isolation compressor mounts for quiet operation, thermal expansion valves for refrigerant metering, and 22.2mm & 28.6mm electrical
knockouts to accommodate fi eld wiring.
FPT - Female Pipe Thread
Condensate Drain Connection is 3/4” FPT
Unit Maximum Water Working Pressure
Options Max Pressure kPa
Base Unit 3447
Tranquility
®
16 (TC) Series (50 Hz)
