Electrical - Line Voltage
Table 4a: Tranquility 27™ (TT) Series Electrical Data (Standard Units)
All TT Units Standard TT Units
Model
Voltage
Code
Voltage
Min/Max
Voltage
Compressor
Fan
Motor FLA
Total
Unit FLA
Min
Circuit Amp
Max
Fuse/ HACR
QTY RLA LRA
TTH/V/D 026
G 208-230/60/1 197/254 1 10.3 52.0 4.3 14.6 17.2 25
TTH/V/D 038
G 208-230/60/1 197/254 1 16.7 82.0 4.3 21.0 25.2 40
H 208-230/60/3 197/254 1 11.2 58.0 4.3 15.5 18.3 25
F* 460/60/3*
414/506 1 4.5 29.0 4.1 8.6 9.7 15
TTH/V/D 049
G 208-230/60/1 197/254 1 21.2 96.0 7.0 28.2 33.5 50
H 208-230/60/3 197/254 1 13.5 88.0 7.0 20.5 23.9 35
F* 460/60/3*
414/506 1 6.4 41.0 6.9 13.3 14.9 20
TTH/V/D 064
G 208-230/60/1 197/254 1 25.6 118.0 7.0 32.6 39.0 60
H 208-230/60/3 197/254 1 17.6 123.0 7.0 24.6 29.0 45
F* 460/60/3*
414/506 1 9.0 62.0 6.9 15.9 18.2 25
TTH/V/D 072
G 208-230/60/1 197/254 1 27.2 150.0 7.0 34.2 41.0 60
HACR circuit breaker in USA only
Wire length based on one way measurement with 2% voltage drop
Wire size based on 60°C copper conductor
All fuses Class RK-5
* NEUTRAL CONNECTION REQUIRED! All F Voltage (460 vac) units with ECM motors require a four wire power supply
with neutral. ECM motor is rated 265 vac and is wired between one hot leg and neutral.
All TT Units TT Units with ClimaDry TT Units with Secondary Pump
Model
Voltage
Code
Voltage
Min/Max
Voltage
Reheat
Pump FLA
Total
Unit FLA
Min
Circuit Amp
Max
Fuse/HACR
Pump
FLA
Total
Unit FLA
Min
Circuit
Amp
Max
Fuse/
HACR
TTH/V/D
026
G 208-230/60/1 197/254 0.8 15.4 18.0 25 0.43 15.0 17.6 25
TTH/V/D
038
G 208-230/60/1 197/254 0.8 21.8 26.0 40 0.8 21.8 26.0 40
H 208-230/60/3 197/254 0.8 16.3 19.1 30 0.8 16.3 19.1 30
F* 460/60/3*
414/506 0.7 9.3 10.4 15 0.7 9.3 10.4 15
TTH/V/D
049
G 208-230/60/1 197/254 1.07 29.3 34.6 50 0.8 29.0 34.3 50
H 208-230/60/3 197/254 1.07 21.6 24.9 35 0.8 21.3 24.7 35
F* 460/60/3*
414/506 1.07 14.4 16.0 20 0.7 14.0 15.6 20
TTH/V/D
064
G 208-230/60/1 197/254 1.07 33.7 40.1 60 1.07 33.7 40.1 60
H 208-230/60/3 197/254 1.07 25.7 30.1 45 1.07 25.7 30.1 45
F* 460/60/3*
414/506 1.07 17.7 19.2 25 1.07 17.0 19.2 25
TTH/V/D
072
G 208-230/60/1 197/254 1.07 35.3 42.1 60 1.07 35.3 42.1 60
HACR circuit breaker in USA only
Wire length based on one way measurement with 2% voltage drop
Wire size based on 60°C copper conductor
All fuses Class RK-5
* NEUTRAL CONNECTION REQUIRED! All F Voltage (460 vac) units with ECM motors/ClimaDry/internal secondary
circulators require a four wire power supply with neutral. ECM motors/reheat pumps/internal secondary circulators
are rated 265 vac and are wired between one hot leg and neutral.
Table 4b: Tranquility 27™ (TT) Series Electrical Data Units with Secondary Pump or ClimaDry Reheat
