ClimateMaster Tranquility 27 (TT) Series User Manual

43
climatemaster.com
THE SMART SOLUTION FOR ENERGY EFFICIENCY
Packaged Units
Rev.: 1/06/09B
Electrical - Line Voltage
All GC Units Standard GC Unit GCV Units with ClimaDry
Model
Voltage
Code
Voltage
Min/
Max
Voltage
Compressor
Fan
Motor
FLA
Total
Unit
FLA
Min
Circuit
Amps
Max
Fuse/
HACR
Reheat
Pump
FLA
Total
Unit
FLA
Min
Cir-
cuit
Amps
Max
Fuse/
HACR
QTY RLA LRA
GCH/V
018
G 208-230/60/1 197/254 1 8.6 49.0 1.0 9.6 11.8 20 0.80 10.4 12.6 20
E 265/60/1 239/292 1 8.1 44.0 0.9 9.0 11.0 15 0.70 9.7 11.7 15
GCH/V
024
G 208-230/60/1 197/254 1 9.6 50.0 3.0 12.6 15.0 20 0.80 13.4 15.8 25
E 265/60/1 239/292 1 9.1 55.0 2.7 11.8 14.1 20 0.70 12.5 14.8 20
H 208-230/60/3 197/254 1 6.7 51.0 3.0 9.7 11.4 15 0.80 10.5 12.2 15
F
* 460/60/3*
414/506 1 3.5 25.0 1.7 5.2 6.1 15 0.70 5.9 6.8 15
GCH/V
030
G 208-230/60/1 197/254 1 11.2 61.0 3.0 14.2 17.0 25 0.80 15.0 17.8 25
E 265/60/1 239/292 1 10.0 58.0 2.7 12.7 15.2 25 0.70 13.4 15.9 25
H 208-230/60/3 197/254 1 6.9 55.0 3.0 9.9 11.6 15 0.80 10.7 12.4 15
F
* 460/60/3*
414/506 1 3.6 28.0 1.7 5.3 6.2 15 0.70 6.0 6.9 15
GCH/V
036
G 208-230/60/1 197/254 1 15.4 82.0 3.0 18.4 22.3 35 0.80 19.2 23.1 35
E 265/60/1 239/292 1 14.4 83.0 2.7 17.1 20.7 35 0.70 17.8 21.4 35
H 208-230/60/3 197/254 1 9.6 70.0 3.0 12.6 15.0 20 0.80 13.4 15.8 20
F
* 460/60/3*
414/506 1 4.9 33.0 1.7 6.6 7.8 15 0.70 7.3 8.5 15
GCH/V
042
G 208-230/60/1 197/254 1 17.1 105.0 3.0 20.1 24.4 40 0.80 20.9 25.2 40
H 208-230/60/3 197/254 1 10.7 85.0 3.0 13.7 16.4 25 0.80 14.5 17.2 25
F
* 460/60/3*
414/506 1 5.3 42.0 1.7 7.0 8.3 15 0.70 7.7 9.0 15
N 575/60/3 518/633 1 4.3 34.0 1.4 5.7 6.8 15 N/A N/A N/A N/A
GCH/V
048
G 208-230/60/1 197/254 1 18.3 102.0 4.9 23.2 27.8 45 1.07 24.3 28.8 45
H 208-230/60/3 197/254 1 12.6 91.0 4.9 17.5 20.7 30 1.07 18.6 21.7 30
F
* 460/60/3*
414/506 1 5.7 42.0 2.5 8.2 9.6 15 1.00 9.3 10.7 15
N 575/60/3 518/633 1 4.7 39.0 1.9 6.6 7.8 15 N/A N/A N/A N/A
GCH/V
060
G 208-230/60/1 197/254 1 25.6 170.0 5.8 31.4 37.8 60 1.07 32.5 38.9 60
H 208-230/60/3 197/254 1 14.7 124.0 5.8 20.5 24.2 35 1.07 21.6 25.2 35
F
* 460/60/3*
414/506 1 7.4 59.6 2.6 10.0 11.9 15 1.00 11.1 12.9 20
N 575/60/3 518/633 1 5.9 49.4 2.3 8.2 9.7 15 N/A N/A N/A N/A
HACR circuit breaker in USA only
All fuses Class RK-5
* NEUTRAL CONNECTION REQUIRED! All F Voltage (460 vac) units with ClimaDry require a four wire power supply
with neutral. Reheat pump is rated 265 vac and is wired between one hot leg and neutral.
Table 4p: Genesis Compact (GC) Series Electrical Data - (High Static Blower Motor)
