ClimateMaster Water-Source Heating and Cooling Systems
CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Packaged Units
Rev.: 1/06/09B
Unit Physical Data
Tranquility 20™ Single-Stage (TS) Series (50Hz)
Model 006 009 012 018 024 030 036 042 048 060 070
Compressor (1 Each) Rotary Scroll
Factory Charge R410A
(oz) [kg]
24 [0.68] 31 [0.88] 34 [0.96] 50 [1.13] 56 [1.59] 58 [1.64] 70 [1.98] 80 [2.27] 80 [2.27] 136 [3.86] 144 [4.08]
PSC Fan Motor & Blower (3 Speeds)
Fan Motor (hp) [W] 1/25 [30] 1/20 [37] 1/8 [93] 1/6 [124] 1/5 [149] 1/3 [249] 1/2 [373] 1/2 [373] 3/4 [560] 1 [746] 1 [746]
High Static Fan Motor (hp) [W] N/A N/A N/A 1/5 [149] 1/3 [249] 1/2 [373] 1/2 [373] 3/4 [560] 3/4 [560] 1 [746] Not Available
Blower Wheel Size (dia x w) -
(in) [mm]
6 X 5
[152 X 127]
6 X 5
[152 X 127]
6 X 5
[152 X 127]
9 x 7
[229 x 178]
9 x 7
[229 x 178]
9 x 7
[229 x 178]
10 x 10
[254 x 254]
10 x 10
[254 x 254]
10 x 10
[254 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
Water Connection Size
IPT (in) 1/2” 1/2” 1/2” 3/4” 3/4” 3/4” 3/4” 1” 1” 1” 1”
HWG Connection Size
IPT (in) N/A N/A N/A 1/2” 1/2” 1/2” 1/2” 1/2” 1/2” 1/2” 1/2”
Coax Volume
Volume (US Gallons) [liters] 0.17 [0.64] 0.29 [1.10] 0.45 [1.70] 0.56 [2.12] 0.76 [2.88] 0.76 [2.88] 0.92 [3.48] 1.24 [4.69] 1.24 [4.69] 1.56 [5.91] 1.56 [5.91]
Vertical Upfl ow/Downfl ow
Air Coil Dimensions (h x w) -
(in) [mm]
16 x 16
[406 x 406]
Upfl ow Only
16 x 16
[406 x 406]
Upfl ow Only
16 x 16
[406 x 406]
Upfl ow Only
24 x 20
[610 x 508]
28 x 20
[711 x 508]
28 x 20
[711 x 508]
28 x 25
[711 x 635]
32 x 25
[813 x 635]
32 x 25
[813 x 635]
36 x 25
[914 x 635]
36 x 25
[914 x 635]
Standard Filter - 1” [25.4mm]
Throwaway, qty (in) [mm]
16 x 20
[406 x 508]
16 x 20
[406 x 508]
16 x 20
[406 x 508]
24 x 24
[610 x 610]
28 x 24
[711 x 610]
28 x 24
[711 x 610]
28 x 30
[711 x 762]
2 - 16 x 30
[2 - 406 x
762]
2 - 16 x 30
[2 - 406 x
762]
1 - 16 x 30;
1 - 20 x 30
[1 - 406 x 762;
1 - 508 x 762]
1 - 16 x 30;
1 - 20 x 30
[1 - 406 x 762;
1 - 508 x 762]
Weight - Operating, (lbs) [kg] 126 [57] 146 [66] 150 [68] 252 [114] 266 [121] 268 [122] 327 [148] 414 [188] 416 [189] 441 [200] 443 [201]
Weight - Packaged, (lbs) [kg] 136 [62] 156 [71] 160 [73] 262 [119] 276 [125] 278 [126] 337 [153] 424 [192] 426 [193] 451 [205] 453 [206]
Horizontal
Air Coil Dimensions (h x w) -
(in) [mm]
16 x 16
[406 x 406]
16 x 16
[406 x 406]
16 x 16
[406 x 406]
18 x 27
[457 x 686]
18 x 31
[457 x 787]
18 x 31
[457 x 787]
20 x 35
[508 x 889]
20 x 40
[508 x 1016]
20 x 40
[508 x 1016]
20 x 45
[508 x 1143]
20 x 45
[508 x 1143]
Standard Filter - 1” [25.4mm]
Throwaway, qty (in) [mm]
16 x 20
[406 x 508]
16 x 20
[406 x 508]
16 x 20
[406 x 508]
2 - 18 x 18
[2 - 457 x 457]
2 - 18 x 18
[2 - 457 x 457]
2 - 18 x 18
[2 - 457 x 457]
1 - 12 x 20;
1- 20 x 25
[1 - 305 x 508;
1 - 508 x 635]
1 - 18 x 20;
1 - 20 x 24
[1 - 457 x 508;
1 - 508 x
610]
1 - 18 x 20;
1 - 20 x 24
[1 - 457 x 508;
1 - 508 x
610]
2 - 20 x 24
[2 - 508 x 610]
2 - 20 x 24
[2 - 508 x 610]
Weight - Operating, (lbs) [kg] 136 [62] 156 [71] 160 [73] 257 [117] 266 [121] 268 [122] 327 [148] 414 [188] 416 [189] 441 [200] 443 [201]
Weight - Packaged, (lbs) [kg] 146 [66] 166 [72] 170 [77] 267 [121] 276 [125] 278 [126] 337 [153] 424 [192] 426 [193] 451 [205] 453 [206]
All units have spring compressor mountings, TXV expansion devices, and 1/2” [12.2mm] & 3/4” [19.1mm] electrical knockouts.
