19
Residential H&V - 60Hz HFC-410A
Rev.: 9 March, 2011B
climatemaster.com
Electrical - Line Voltage
WARNING! CAUTION!
WARNING! To avoid possible injury or death due to
electrical shock, open the power supply disconnect switch
and secure it in an open position during installation.
CAUTION! Use only copper conductors for fi eld installed
electrical wiring. Unit terminals are not designed to accept
other types of conductors.
Standard TS Unit TS Unit with ClimaDry
Model
Compressor
HWG
Pump
FLA
Ext
Loop
Pump
FLA
Fan
Motor
FLA
Total
Unit
FLA
Min
Circuit
Amps
Max
Fuse/
HACR
(2)
ClimaDry
Pump
FLA
Total
Unit
FLA
Min
Circuit
Amps
Max Fuse/
HACR (2)
RLA LRA Qty
PSC Electrical Data
018 9.0 48.0 1 0.40 4.0 1.0 14.4 16.7 25 0.8 15.2 17.5 25
024 12.8 60.0 1 0.40 4.0 1.1 18.3 21.5 30 0.8 19.1 22.3 35
030 13.5 61.0 1 0.40 4.0 1.4 19.3 22.7 35 0.8 20.1 23.5 35
036 14.7 72.5 1 0.40 4.0 2.1 21.2 24.9 35 0.8 22.0 25.7 40
042 15.4 83.0 1 0.40 4.0 2.1 21.9 25.8 40 0.8 22.7 26.6 40
048 20.5 109.0 1 0.40 4.0 3.0 27.9 33.0 50 1.07 29.0 34.1 50
060 26.9 145.0 1 0.40 4.0 4.9 36.2 42.9 60 1.07 37.3 44.0 70
ECM Electrical Data
018 9.0 48.0 1 0.40 4.0 3.9 17.3 19.6 25 0.8 18.1 20.4 25
024 12.8 60.0 1 0.40 4.0 3.9 21.1 24.3 35 0.8 21.9 25.1 35
030 13.5 61.0 1 0.40 4.0 3.9 21.8 25.2 35 0.8 22.6 26.0 35
036 14.7 72.5 1 0.40 4.0 3.9 23.0 26.7 40 0.8 23.8 27.5 40
042 15.4 83.0 1 0.40 4.0 3.9 23.7 27.6 40 0.8 24.5 28.4 40
048 20.5 109.0 1 0.40 4.0 6.9 31.8 36.9 50 1.07 32.9 38.0 50
060 26.9 145.0 1 0.40 4.0 6.9 38.2 44.9 70 1.07 39.3 46.0 70
070 30.1 158.0 1 0.40 4.0 6.9 41.4 48.9 70 1.07 42.5 50.0 80
Table 4a: Tranquility
®
27 (TT) Series Electrical Data
Table 4b: Tranquility
®
20 (TS) Series Electrical Data
Rated Voltage of 208-230/60/1 Min/Max Voltage of 197/254
HACR circuit breaker in USA only All fuses Class RK-5
All TT Units with Emerson ECM Fan Motor TT Units (ECM) Standard TT Units (ECM) with ClimaDry
Model
Compressor
HWG
Pump
FLA
Ext
Loop
Pump
FLA
Fan
Motor
FLA
Total
Unit
FLA
Min
Circuit
Amps
Max
Fuse/
HACR
(2)
ClimaDry
Pump
FLA
Total
Unit
FLA
Min
Circuit
Amps
Max/
Fuse
HACR
(2)
RLA LRA Qty
026 10.3 52.0 1 0.40 4.0 3.9 18.6 21.2 30 0.8 19.4 22.0 30
038 16.7 82.0 1 0.40 4.0 3.9 25.0 29.2 45 0.8 25.8 30.0 45
049 21.2 96.0 1 0.40 4.0 6.9 32.5 37.8 50 1.07 33.6 38.9 60
064 25.6 118.0 1 0.40 4.0 6.9 36.9 43.3 60 1.07 38.0 44.4 60
072 27.2 150.0 1 0.40 4.0 6.9 38.5 45.3 70 1.07 39.6 46.4 70
Rated Voltage of 208-230/60/1 Min/Max Voltage of 197/254
HACR circuit breaker in USA only All fuses Class RK-5
