ClimateMaster Tranquility Digital - 1-Inch Modulating Valve Powerhead Removal

13
Troubleshooting Guide - Tranquility
®
Digital (DXM2) Packaged Units
Rev.: 01/15/14
Removing Powerhead on 1-Inch Modulating Valve
A-C
A-C
2) The 1-inch valve includes
a tool to remove the
power head.
See previous page for
proper valve-to-head
alignment.
Open
Closed
1) Rotate dial to ‘1’ on the
1-Inch valve.
