ClimateMaster Tranquility TCV 030 User Manual

climatemaster.com
45
Tranquility
®
Compact (TC) Series
Rev.: July 7, 2020
THE SMART SOLUTION FOR ENERGY EFFICIENCY
Blower Performance Data – TC036
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
1150 900 PSC
Low CFM 970 960 951 941 902
Medium CFM 1106 1096 1086 1067 1009 912
High CFM 1436 1387 1329 1280 1174 1077 931
1150 900
PSC -
High
Static
Low CFM 980 970 960 931 902
Medium CFM 1300 1280 1261 1222 1193 1116 1038
High CFM 1484 1426 1358 1251 1135 931
1150 900
ECM -
Constant
Torque
1
RPM 842 891 945
Power (W) 166 175 184
CFM 974 941 904
2
RPM 936 983 1028 1075 1125 1167 1203 1241
Power (W) 241 251 261 272 282 292 299 307
CFM 1132 1103 1074 1041 1005 973 944 916
3
RPM 988 1032 1076 1117 1160 1205 1246 1282 1315 1354
Power (W) 294 304 316 326 337 349 359 367 375 385
CFM 1271 1242 1214 1185 1153 1118 1083 1056 1029 999
4
RPM 1056 1090 1130 1170 1208 1250 1292 1332 1370 1403
Power (W) 376 387 399 409 421 433 446 457 468 478
CFM 1403 1377 1351 1324 1295 1268 1233 1201 1169 1143
5
RPM 1193 1228 1265 1295 1323 1358 1392 1419
Power (W) 499 510 523 524 521 519 516 514
CFM 1485 1460 1434 1396 1347 1295 1240 1194
1150 900
ECM -
Constant
Volume
Minimum CFM
RPM 682 788 898 976 1043 1107 1170 1230 1297 1371
Power (W) 105 132 164 188 211 233 257 280 307 339
CFM 900 900 900 900 900 900 900 900 900 900
Default CFM
RPM 830 895 961 1054 1145 1209 1267 1321 1371 1419
Power (W) 205 232 261 303 349 382 415 446 475 505
CFM 1150 1150 1150 1150 1150 1150 1150 1150 1150 1150
Maximum CFM
RPM 1042 1040 1095 1149 1199 1273 1355 1420 1459 1493
Power (W) 406 403 438 474 511 564 629 680 692 691
CFM 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500
See ECM control section for details on setting airow.
Airow is controlled within 5% up to the Max ESP shown with wet coil.
Do not select Dehumidication mode if HP CFM is on setting 1.
ClimaDry is factory wired to operate in stage 2 airow.
Black areas denote ESP where operation is not recommended.
PSC: Units factory shipped on medium speed. Other speeds require eld selection.
CT ECM: Units factory shipped on Speed Tap 2 for Fan-Only and Speed Tap 3 for Heating/Cooling.
All airow is rated and shown above at the lower voltage if unit is dual voltage rated, e.g. 208V for 208-230V units.
Only two speed PSC fan (H & M) available on 575V units.
Performance stated is at the rated power supply. Performance may vary as the power supply varies from the rated.
All data is shown wet coil with clean 1” lter.
All data is ran at 80 °F DB and 67 °F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.
