ClimateMaster Tranquility TCV 030 User Manual

climatemaster.com
47
Tranquility
®
Compact (TC) Series
Rev.: July 7, 2020
THE SMART SOLUTION FOR ENERGY EFFICIENCY
Blower Performance Data – TC042
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
1400 1050 PSC
Low CFM 1074 1064
Medium CFM 1368 1321 1273 1207 1131 1064
High CFM 1501 1444 1378 1302 1226 1131
1400 1050
PSC -
High
Static
Low CFM
Medium CFM 1302 1283 1254 1235 1188 1121
High CFM 1473 1444 1397 1378 1311 1178
1400 1050
ECM -
Constant
Torque
1
RPM 916 957 1004 1065
Power (W) 238 248 259 272
CFM 1186 1152 1113 1056
2
RPM 1013 1050 1084 1128 1179 1227 1279 1317 1356 1400
Power (W) 331 369 352 365 381 396 411 423 437 446
CFM 1345 1317 1283 1251 1215 1181 1150 1124 1094 1050
3
RPM 1108 1142 1178 1207 1247 1293 1336 1382 1426 1462
Power (W) 448 461 474 486 501 518 534 551 568 581
CFM 1507 1482 1455 1427 1396 1365 1331 1296 1276 1246
4
RPM 1200 1231 1263 1292 1321 1356 1397 1440 1479 1505
Power (W) 582 595 609 622 635 651 669 688 706 681
CFM 1641 1623 1601 1577 1548 1519 1488 1455 1423 1355
5
RPM 1317 1372 1392 1412 1436 1469 1500 1504
Power (W) 756 775 776 774 772 768 765 679
CFM 1743 1717 1688 1645 1596 1541 1490 1352
1400 1050
ECM -
Constant
Volume
Minimum CFM
RPM 786 855 920 985 1059 1125 1186 1240 1292 1346
Power (W) 154 177 200 224 252 280 306 331 355 383
CFM 1050 1050 1050 1050 1050 1050 1050 1050 1050 1050
Default CFM
RPM 997 1042 1094 1145 1193 1241 1292 1345 1400 1451
Power (W) 334 359 390 421 453 484 517 555 595 636
CFM 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400
Maximum CFM
RPM 1224 1245 1282 1305 1327
Power (W) 658 674 703 700 697
CFM 1750 1750 1750 1750 1750
See ECM control section for details on setting airow.
Airow is controlled within 5% up to the Max ESP shown with wet coil.
Do not select Dehumidication mode if HP CFM is on setting 1.
ClimaDry is factory wired to operate in stage 2 airow.
Black areas denote ESP where operation is not recommended.
PSC: Units factory shipped on medium speed. Other speeds require eld selection.
CT ECM: Units factory shipped on Speed Tap 2 for Fan-Only and Speed Tap 3 for Heating/Cooling.
All airow is rated and shown above at the lower voltage if unit is dual voltage rated, e.g. 208V for 208-230V units.
Only two speed PSC fan (H & M) available on 575V units.
Performance stated is at the rated power supply. Performance may vary as the power supply varies from the rated.
All data is shown wet coil with clean 1” lter.
All data is ran at 80 °F DB and 67 °F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.
