TERMINAL EVOLUTION
CONFIGURATION OF THE TERMINAL AND THE BOARD
AIU
SETTING THE LOCAL NETWORK ADDRESS ON THE
EVOLUTION TERMINAL AND THE pCO1 BOARD
Before setting the addresses, first check the LAN connection
between the boards, the connection to the remote or shared ter-
minal, and the power supply connections to the unit.
The terminal address can be set only after having connected it to
the power supply using the RJ11 telephone connector.
To enter configuration mode, press the UP ENTER DOWN but-
tons together (featured on all versions) for at least 5 seconds; the
screen shown in Fig. 1 will be displayed, with the cursor flashing in
the top left corner:
• To set the address of the terminal (display address setting), press
the ENTER button once: the cursor will move to the address
field (nn).
• Use the UP and DOWN buttons to select the desired value,
and confirm by pressing ENTER again.
If the value selected is different from the one saved previously,
the screen shown in Fig. 2 will be displayed and the new value
will be saved to the permanent memory on the display.
If the field nn is set to 0, the terminal will communicate with the
pCO1 board using the “point-to-point” protocol (not pLAN), and
the field XX will not be displayed, as it no longer has meaning.
fig. 1
fig. 2
pCO1: assigning the list of private and shared terminals
Subsequently, to modify the list of terminals associated with each
individual pCO1 board, proceed as follows:
• enter configuration mode by pressing UP ENTER DOWN, as
described in the previous paragraph;
• press the ENTER button until the cursor reaches the field XX
(I/O board address) Fig. 1;
• use the UP and DOWN buttons to select the address of the
desired pCO1 board. The values available correspond to the
pC01 boards that are effectively on line. If the pLAN network is
not working correctly, or no pCO1 board is available, the field
cannot be modified and will show “-”;
• pressing the button once again displays the sequence of screens
shown in Fig. 3;
• again the ENTER button moves the cursor from one field to
the next, and the UP and DOWN buttons change the value of
the current field.
The field P:xx shows the address of the selected board; in the
example in Fig. 3, P12 has been selected.
To exit the configuration procedure and save the data, select the
field “OK ?”, set Yes and confirm by pressing ENTER.
The fields in the “Adr” column represent the addresses of the
terminals associated with the pCO1 board with address 12, while
the Priv/Shared column indicates the type of terminal.
Important: the EVOLUTION terminals cannot be configured as
“Sp” (shared printer), as they have no printer output.
If the terminal remains inactive (no button is pressed) for more
than 30 seconds, it automatically exits the configuration proce-
dure without saving any changes.
Assigning the List of Private and Shared Terminals
fig. 3
LAN ADDRESS OF THE pCO1 BOARD
The address of the boards is set as described below:
1 Disconnect the power supply from the board UPC1m;
2 Remove the J11 connector (Rx/Tx-, Rx/Tx+, GND);
3 Connect the board on unit no. 1 to a user terminal with
address = 0;
4 Power-up the board and at the same time hold the ALARM
and UP buttons until the following screen is displayed:
and then
5 Press the ENTER button to accept the address of the board proposed
on the display, or alternatively the UP and DOWN buttons to modify
the value: set "pLAN address: 1" on unit no. 1.
(NOTE: if no button is pressed for 15 seconds, the screen disappears,
and the procedure needs to be repeated from point 1.).
6 Confirm by pressing ENTER;
7 Disconnect the power supply;
8 Repeat the procedure from point 1 to point 4 for unit no. 2. and set
"pLAN address: 2 ";
9 Replace the J11 connectors (Rx/Tx-, Rx/Tx+, GND) on the boards.
10 Repeat the procedure from point 1 to point 4 for the other units.
Display address
setting.........:nn
I/O Board address:xx
Display address changed
Terminal Config
Press ENTER to continue
P12: Adr Priv/Shared
Trm1 02 Sh
Trm2 03 Ph
Trm3 None --OK?NO
SELF TESTING
PLEASE WAIT
pLAN address: 1
up: increase
down: decrease
ENTER: save & exit
pLAN address: 2
up: increase
down: decrease
ENTER: save & exit
