Example stored data reports: 2 channels
STORED DATA PRINTOUTS USING
LARGE FONT
(2 CHANNELS)
STORED DATA PRINTOUTS USING
SMALL FONT
(2 CHANNELS)
STORED DATA
#LOCATIONS= 1
#SAMPLES= 4
PROGRAM= CLASS B ZONE 1
06/10/10
ID= default id
VOLUME= 1.0CF
TIME TOTAL COUNT FLOW
13:09:27 >5.0 0 1.00
>0.5 420
13:10:27 >5.0 0 1.00
>0.5 496
13:11:27 >5.0 0 1.00
>0.5 435
13:12:27 >5.0 0 1.00
>0.5 515
STORED DATA
#LOCATIONS = 1 #SAMPLES = 4
PROGRAM= CLASS B ZONE 1
ID= default id 06/10/10
SAMPLE VOL= 1.0CF TOTAL COUNT
TIME >0.5 >5.0 FLOW
13:09:27 420 0 1.00
13:10:27 496 0 1.00
13:11:27 435 0 1.00
13:12:27 515 0 1.00
2.13.5 Printing alarm data
A printout of all alarm violations can be made from the report menu. Access the
report menu by pressing the [REPORT] key from the main data screen. From the next
screen, press [ALARM DATA]. From the alarm data screen, press [PRINT].
Example Alarm Report: 2 channels, 0.5 and 5.0 m
ALARM REPORT USING
LARGE FONT
(2 CHANNELS)
ALARM REPORT USING
SMALL FONT
(2 CHANNELS)
ALARM SETTINGS
>5.0 OFF
>0.5 6000
%FLOW HIGH OFF LOW OFF
ALARM DATA
#LOCATIONS= 1
#SAMPLES= 4
06/16/10
PROGRAM= CLASS B ZONE 1
ID= 1
VOLUME= 1.0CF
TIME TOTAL COUNT FLOW
09:04:30 >5.0 404 1.00
>0.5 69443
09:05:30 >5.0 332 1.00
>0.5 69555
09:06:30 >5.0 133 1.00
>0.5 68395
09:07:30 >5.0 64 1.00
>0.5 68790
ALARM SETTINGS
>0.5 >5.0
6000 OFF
FLOW%
HIGH OFF
LOW OFF
ALARM DATA
#LOCATIONS = 1 #SAMPLES = 4
PROGRAM= CLASS B ZONE 1
ID= 1 06/10/10
SAMPLE VOL= 1.0CF TOTAL COUNT
TIME >0.5 >5.0 FLOW
09:04:30 69443 404 1.00
09:05:30 69555 332 1.00
09:06:30 68395 133 1.00
09:07:30 68790 64 1.00
