CI-154 User’s Manual
Page 34
Example Report: 1 channel, 0.5 m
ISO 14644-1 REPORT
USING LARGE FONT
ISO 14644-1 REPORT
USING SMALL FONT
ISO 14644-1 REPORT
PASS
UNIT= CLIMET #1
ISO CLASS 5 (AT 0.5 uM)
PRINTED 06/16/10 13:50:31
FIRST 06/16/10 13:42:49
LAST 06/16/10 13:46:01
PROGRAM= CLASS B ZONE 1
SAMPLE VOLUME= 0.05CM
SIZE= >0.5
ID= 1
#SAMPLES= 1
AVERAGE COUNTS 32.0
AVERAGE COUNTS/CM 640.0
ID= 2
#SAMPLES= 2
AVERAGE COUNTS 51.5
AVERAGE COUNTS/CM 1030.0
ISO 14644-1 REPORT
PASS
UNIT= CLIMET #1
ISO CLASS 9 (AT 0.5 uM)
PRINTED 06/16/10 13:50:52
FIRST 06/16/10 13:42:49
LAST 06/16/10 13:46:01
PROGRAM= CLASS B ZONE 1
SAMPLE VOLUME= 0.05CM
SIZE= >0.5 uM AVERAGE AVERAGE
ID #SAMPLES COUNTS COUNTS
1 1 32.0 640.0
2 2 51.5 1030.0
2.13.8 Printing an FS-209E report
The FS-209E report screen is accessed from the report menu screen. First select the
particle size or sizes upon which the report is to be based. The particle size buttons
are above the [SET CLASS] key; they will turn green when enabled. Next select [FS-
209E] to enable FS-209E reports. Next press [SET CLASS]; from the screen that
follows, press the desired 209E class for the area being monitored. The selected key
will turn green when pressed. Press [EXIT] to return to the report menu screen.
Next, press the [ISO/209E/GMP] key, and then press the [PRINT] key at the bottom of
the following screen to print the FS-209E report.
Note that minimum sample volume requirements of FS-209E are not considered in
the Pass/Fail criteria. The user is responsible for determining that sampling volume,
proper sampling locations and other requirements such as probe positions are met.
The minimum number of sampling locations may be enforced by entering the area of
the cleanroom when setting the desired class. The report will always include the
program name, and will include the Unit ID if one exists. The report will also include
user ID’s if security is enabled.
