CI-154 User’s Manual
Page 57
The following list provides coil write examples for all coils in the unit.
Note that Modbus coil numbers are offset from the address by 1.
Coil #, Command
MBAP HEADER +
FUNCTION CODE
DATA
101, Set Active
00 01 00 00 00 06 01 05
00 64 FF 00
101, Set Standby
00 01 00 00 00 06 01 05
00 64 00 00
102, Pump On
00 01 00 00 00 06 01 05
00 65 FF 00
102, Pump Off
00 01 00 00 00 06 01 05
00 65 00 00
103, Disable Keyboard
00 01 00 00 00 06 01 05
00 66 FF 00
103, Enable Keyboard
00 01 00 00 00 06 01 05
00 66 00 00
104, Activate Alarm Relay
00 01 00 00 00 06 01 05
00 67 FF 00
104, Deactivate Alarm Relay
00 01 00 00 00 06 01 05
00 67 00 00
1000 Set DMY Date Format
00 01 00 00 00 06 01 05
03 E7 FF 00
1000 Set MDY Date Format
00 01 00 00 00 06 01 05
03 E7 00 00
The following list provides coil read examples for all coils in the unit.
Note that Modbus coil numbers are offset from the address by 1.
Coil #, Current State
MBAP HEADER +
FUNCTION CODE
DATA
101, Active
00 01 00 00 00 06 01 03
00 64 FF 00
101, Standby
00 01 00 00 00 06 01 03
00 64 00 00
102, Pump On
00 01 00 00 00 06 01 03
00 65 FF 00
102, Pump Off
00 01 00 00 00 06 01 03
00 65 00 00
103, Keyboard Disabled
00 01 00 00 00 06 01 03
00 66 FF 00
103, Keyboard Enabled
00 01 00 00 00 06 01 03
00 66 00 00
104, Alarm Relay Activated
00 01 00 00 00 06 01 03
00 67 FF 00
104, Alarm Relay Deactivated
00 01 00 00 00 06 01 03
00 67 00 00
1000 Date Format is DMY
00 01 00 00 00 06 01 03
03 E7 FF 00
1000 Date Format is MDY
00 01 00 00 00 06 01 03
03 E7 00 00
