Model HF-15B High Frequency Spark Tester
HF-15B Instruction Manual – Page 43
Below are the individual bits for Status Word 0
Set when all conditions allow voltage to be generated
Set when the Actual Voltage >= HVL On voltage
Set when voltage is in the range of the Watchdog Low and High levels
Set when the fault is detected and cleared at end of fault pulse duration
State of the AF Alarm cleared by Fault Reset
State of the PH Alarm cleared by Fault Reset
State of the MC Alarm cleared by Fault Reset
State of the MP Alarm cleared by Fault Reset
State of the GB Alarm cleared by Fault Reset
Set if AF Count >= AF Count Limit cleared by Fault Count Reset
Set if PH Count >= PH Count Limit cleared by Fault Count Reset
Set if MC Count >= MC Count Limit cleared by Fault Count Reset
Set if MP Count >= MP Count Limit cleared by Fault Count Reset
Set if GB Count >= GB Count Limit cleared by Fault Count Reset
Set if Fault Co Count >= Fault Co Count Limit cleared by Fault Count Reset
Set when Actual Voltage is within the AVSP Percent of the Setpoint
Below are the individual bits for Status Word 1
Set when Electrode Voltage is within the EVSP Percent of the Setpoint
Indicates a Bare Wire fault has been detected cleared by Fault Reset
Indicates a Pinhole fault has been detected cleared by Fault Reset
Indicates the cover state: 1 – Cover Closed, 0 – Cover is Open
PERCENT_LOAD_LIMIT_STATUS
Indicates if the Percentage Load Limit has been reached or exceeded
Indicates the system has detected an error
State of General Purpose Output 0
State of General Purpose Output 1
State of General Purpose Output 2
State of General Purpose Output 3
State of General Purpose Input 0
State of General Purpose Input 1
State of General Purpose Input 2
State of General Purpose Input 3
