Clinton HF-15B - Warranty

Model HF-15B High Frequency Spark Tester
HF-15B Instruction Manual – Page 57
FS-4 Floor Stand Assembly
Item No.
Item Description
Qty.
1
Test Module
1
2
6 mm Split Lock Washer
4
3
M6 x 16 Hexhead Screw
4
Item No.
Item Description
Qty.
1
Base
1
2
Outer Column
1
3
10-1.5 x 30 mm bolt
2
4
10-1.5 mm Hex Nut
2
5
8 x 1.25 mm Hex Nut
2
6
8-1.5 x 25 mm Bolt
2
7
Column Clamp
1
8
Handle
1
9
Inner Column
1
10
Test Module Mounting Plate
1
11
M6 Split Washer
2
12
M6 x 16 mm Bolt Hex
2
