Model HF-15B High Frequency Spark Tester
HF-15B Instruction Manual – Page 54
Replacement Parts
Part Number
Description
02606
2 amp low breaking time delay fuse, 5x20mm
92281
3 amp low breaking time delay fuse, 5x20mm
91061
Power entry module (ON/OFF Switch)
RC
Display unit complete
92250
Power Supply 200W 48VDC
92073i
Assembly PCB HF-15B Main
92286
Assy Heat Sink HF-15B
BD-12S
Assy Bead Chain BD-12 W/Split Trough
92267
Assy Bead Chain only for BD-12S (Requires 2)
91048
Electrode Mounting Pate for BD-12, BD-13
92240i
Cover Clear Safety for BD-12, BD13
92264
Hinge Surface Mount 40 Series (Requires 2)
92356i
Assy Transformer High Voltage 15kV HF-15B Only
03004
Switch, Interlock
92283
4 – Pin Terminal Block Connector Kit (Green)
91069
9 – Pin Terminal Block Connector Kit (Green)
03780
Power Cord
91463G
End Guard HF-15B/BD-12 and BD-13
91326
BD-22S Bead Chain Assembly
92241i
Cover Clear Safety for BD-22
01554
Standoff-Ceramic
90819
Rubber Gasket for 01554
91113
Electrode Mounting Plate for BD-22
91111G
End Guard BD-22
92211
Front Panel for RC Display
