CLIVET ELFOFresh2 CPAN-U 70-120 Series User Manual

48 ELFOFresh² BT15B012GB-00
PAIR50X - Suction/supply plenum with AIRJET 50 control damper - rear connection
PAIR80X - Suction/supply plenum with AIRJET 80 control damper - rear connection
The plenums are used to complete the supply diusers and for the extraction grilles.
The plenum is equipped with a control damper ensuring accurate airow adjustment.
The rear part is suitably congured for connection to various exible round or at pipes through the special CBT90X connector.
Two sizes are available:
Plenum with AIRJET 50 control damper
Plenum with AIRJET 80 control damper
1 - Supply diuser or Intake grille
Accessory separately supplied
2 - Plenum with damper
3 - CBT90X connector
Accessory separately supplied
4 - Calibration damper
GINOX - Suction/supply rectangular grill 350x130 stainless
GIVEX - Suction/supply rectangular grill 350x130 white
Grille for oor, wall or ceiling installation.
Floor installation is possible for a system of just mechanical ventilation (e.g. ELFOFresh
2
)
while it is inadvisable for the system with integration (e.g. ElfoPack) that would generate air
stratications and uneven temperature levels.
FREX - Filter for rectangular grilles 350x130mm (5 pcs.)
Simple at lter for rectangular grilles measuring 350x130 mm.
Provided in boxes of 5 pieces.
