BT15B012GB-00 ELFOFresh² 57
A90GPX - 90-degree adaptor, single tube for at grill 350x130 mm
It is used to connect the at grilles to the air distribution system; you can shorten the height with
a cutting tool.
Can be quickly installed thanks to incorporated mounting lugs on the wall as well as on the oor.
A connection and sealing joint for at tubes (GIUPX) allows easy connection of the at tube to the
adapter.
In cases with round tube air distribution it is necessary to provide an RTPTX joint for round tube/
at pipe connection.
Dp = pressure drop
Q = Air ow
TACPX - Cap for at tube (5 pcs.)
The cap can be applied to unused inlets/outlets of the distribution box and to 90° round tube adapters for valves
with 2 inlets.
No sealing ring is required for mounting the cap.
Provided in boxes of 5 pieces.
ANFPX - Fixing ring for at tube (10 pcs.)
The at exible tube can be secured to the wall using an appropriate xing ring, which – on its own – is able
to anchor the tube vertically, horizontally or onto the ceiling, and secure the connections to the exible duct.
Provided in boxes of 10 pieces.
