COBPX - DN90 connector joint (CBT90X) --> at tube
The connection between the at exible tube and the distribution box must be carried out using
the appropriate joint.
The connector is secured to the box by means of a quick-mount pressure tting system and a
sealing ring positioned on the central groove, while the tube is coupled to the connector using an
appropriate joint for at exible tubes with double sealing ring.
Dp = pressure drop
Q = Air ow
CVP90X - Vertical 90-degree curve for at tube
If the bend must have a smaller radius, 90° stamped vertical elbows can be used.
The exible tube can be attached exclusively using an appropriate joint for at exible tubes with
double sealing ring.
Dp = pressure drop
Q = Air ow
GIUPX - Seal and connecting joint for at tube (10 pcs.)
The connection between two sections of a at exible tube must be eected using the appropriate joint.
The connection is carried out on both sides using 2 sealing rings supplied already mounted in the joint..
Provided in boxes of 10 pieces.
*** Joint included for at exible tube with double sealing ring.
*** Joint included for at exible tube with double sealing ring.
