REPPX - Flow controller for at tube
To adjust the amount of air conveyed to an intake/exhaust valve or grille, a ow regulator
(diaphragm with closed sections) must be installed.
The ow regulator has 8 sections (1, 2, 3, 4, 4a, 3a, 2a, 1a). Depending on the required need, one
or more sections can be added to adjust the airow.
Dp = pressure drop
Q = Air ow
A
1 opening
1 or 1a
F
4 openings
1, 2 and 1a, 2a
B
1 opening
4 or 4a
G
4 openings
3, 4 and 3a, 4a
C
2 openings
1 and 1a
H
6 openings
1, 2, 3 and 1a, 2a, 3a
D
2 openings
2 and 2a
I
6 openings
2, 3, 4 and 2a, 3a, 4a
E
2 openings
3 and 3a
L all open
RTPTX - Round/at tube connecting joint
The connection between two sections of a at exible tube must be eected using the appropriate
joint.
The connection is eected on both sides of the joint using 1 sealing ring mounted on the second
rib of the tube, by means of a quick-mount pressure tting system.
Dp = pressure drop
Q = Air ow
