BT15B012GB-00 ELFOFresh² 61
GR150 - Wall-mounted square exhaust/return grille with circular DN150 connection
GR200 - Wall-mounted square exhaust/return grille with circular DN200 connection
GR250 - Wall-mounted square exhaust/return grille with circular DN250 connection
The outdoor air return and exhaust can be carried out on the wall by reaching this exhaust/intake grille with the
pipe.
There are two available grids:
•
DN150 for ELFOFresh2 70-120 sizes
•
DN200 for ELFOFresh2 200-300 sizes and ElfoPack 5 size
•
DN250 for ELFOFresh2 500-650 sizes
The grille is square and tted with small openings to install it on outdoor walls and can be used both for supply
and return purposes.
It is tted with a circular connection at the back tted with a sealing gasket and a wire mesh bird screen
Grille size A B C Weight
Diameter [Ø] [mm] [mm] [mm] [kg]
150 226 206 40 1.4
200 310 276 40 1.5
250 370 336 40 1.9
Air inlet Discharged air
