9.2 TECHNICAL DATA : BASE configuration
9 - TECHNICAL INFORMATION
SIZE 21 25 31 41 51 61 81
Type of internal compressor SCROLL SCROLL SCROLL SCROLL SCROLL SCROLL SCROLL
No. of internal compressor Nr 1 1 1 1 1 1 1
Refrigerant charge (R407C) 7 kg 3.1 5.8 5.8 5.8 6.2 7.5 8.0
Std Capacity control steps Nr 1 1 1 1 1 1 1
Refrigerant circuits Nr 1 1 1 1 1 1 1
COMPRESSOR
Type of internal exchanger 8 PHE PHE PHE PHE PHE PHE PHE
No. of internal exchangers Nr 1 1 1 1 1 1 1
Water flow rate 1 l/s 0.29
0.39 0.48 0.54 0.67 0.85 1.09
Exchanger pressure drops 1 kPa 18 19 20 23 23 20 25
Water content l 0.5 0.6 0.7 0.7 0.8 1.1 1.4
INTERNAL EXCHANGER
Type of fans 9 AX AX AX AX AX AX AX
Number of fans Nr 1 1 1 1 1 1 1
Standard air flow m
3
/h 2500 2800 3200 3400 3400 7000 8000
FANS
Sound pressure level (10m) 6 dB(A) 31 33 35 36 37 43 44
Max water side pressure kPa 270 270 270 270 270 270 270
Safety valve calibration
kPa 300 300 300 300 300 300 300
Water fittings
1” 1” 1” 1” 1” 1 ¼” 1¼”
HYDRAULIC CIRCUIT
Length mm 1370 1370 1370 1370 1370 1625 1625
Depth mm 800 800 800 800 800 1250 1250
Height mm 1515 1515 1515 1515 1515 1765 1765
Unit packing volume m
3
1.67 1.67 1.67 1.67 1.67 2.12 2.12
Casing packing volume m
3
1.08 1.08 1.08 1.08 1.08 1.37 1.37
Unit / panels / hoods shipping weight kg 108/37/50 108/37/50 113/37/50 113/37/50 133/37/50 195/55/75 255/55/75
Operating weight kg 195 205 210 210 235 315 375
DIMENSIONS / STANDARD UNIT WEIGHTS
HEATING A7(6)W30/35
Heat output 1 kW
6.13 8.16 10.0 11.2 14.0 17.7 22.9
Total power input 1 kW
1.57 2.05 2.51 2.87 3.55 4.42 5.87
COP
EUROVENT
4
3.95 4.03 4.03 3.96 4.00 4.06 3.96
COP
EN14511
3.91 3.98 3.98 3.90 3.94 4.01 3.90
COP
EN14511
(with high efficiency option only in heating)
4.10 4.12 4.10 4.16 4.11 4.14 4.10
COOLING A35W23/18
Cooling capacity 3 kW
6.44 8.50 10.7 11.9 14.5 18.1 22.4
Total power input 3 kW
2.26 2.99 3.81 4.46 5.61 6.26 8.07
EER
EUROVENT
4
2.88 2.87 2.83 2.68 2.61 2.92 2.81
230/1/50
Heat output 1 kW
6.22 7.91 10.2 11.3
- - -
Total power input 1 kW
1.69 2.03 2.73 3.01
- - -
COP
EUROVENT
4 kW
3.72 3.94 3.78 3.80
- - -
COP
EN14511
(with high efficiency option only in heating)
4.10 4.14 4.11 4.12 - - -
COP
EN14511
3.69 3.90 3.73 3.75
- - -
COOLING A35W23/18
Cooling capacity 3 kW
6.46 8.03 10.3 11.9
- - -
Total power input 3 kW
2.47 3.15 4.11 4.76
- - -
EER
EUROVENT
4
2.64 2.57 2.52 2.52
- - -
Heat output 2 kW
4.81 6.49 7.83 8.80 11.1 13.9 18.1
Total power input 2 kW
1.49 1.92 2.35 2.72 3.33 4.11 5.48
COP
EN14511
3.24 3.38 3.33 3.24 3.34 3.38 3.31
400/3/50+N
HEATING A2(1)W30/35
HEATING A7(6)W30/35
HEATING A2(1)W30/35
Heat output 2 kW
4.92 6.25 8.01 8.91
- - -
Total power input 2 kW
1.59 1.90 2.54 2.83
- - -
COP
EN14511
3.10 3.29 3.15 3.14
- - -
ESEER 5
2.38 2.49 2.41 2.47 - - -
ESEER 5 2.62 2.62 2.71 2.57 2.46 2.74 2.51
NOISE LEVELS
All of the above data are compliant with standard EN 14511-1:2008 unless otherwise
specified.
Defrost cycles have already been taken into consideration.
Performance refers to a unit operating in optimal conditions of installation with the heat
exchangers perfectly clean.
