7
A condensate water draining
B external enthalpy probe (optional)
C power supply
D multifunction keypad
E radiant panels
F water supply (acqueduct)
G DHW use
V three-way valve for domestic hot water (option)
1.4 SYSTEM DIAGRAM
1.4 SYSTEM DIAGRAM WITH SYSTEM ACCESSORIES
1 - GENERAL
A
BC ED F
V
G
A
B
C
Example of system composed of:
KVICX Boiler control kit(A + YVA + YVB + BT6)
ACS300X 300 litres sanitary hot water tank - ACS500X 500 litres (B)
KGPRX Mixing group control module (C)
n / number of wires : 2 / = 2 wires
