CLIVET WSAT-2 User Manual

24
®
Electrical Connections
Version S / Configuration LN
SIZE 302 323 404 464 524 564 614
F.L.A. Full load current at max admissible conditions
Compressor 1 400/3/50 [A] 29.8 19.5 19.5 25.3 25.3 29.2 29.8
Compressor 2 400/3/50 [A] 29.8 29.2 19.5 19.5 25.3 25.3 29.8
Compressor 3 400/3/50 [A] - 19.5 19.5 25.3 25.3 29.2 29.8
Compressor 4 400/3/50 [A] - - 19.5 19.5 25.3 25.3 29.8
External fan 400/3/50 [A] 2.3 2.3 2.3 2.3 2.3 2.3 2.3
Nr. of fans - 2 2 2 3 3 3 3
Pump 400/3/50 [A] 3.1 3.1 3.1 3.8 3.8 5.0 5.0
Total 400/3/50 [A] 69.5 78.1 87.9 102.5 114.1 123.0 133.2
L.R.A. Locked rotor current
Compressor 1 400/3/50 [A] 198.0 130.0 130.0 175.0 175.0 175.0 198.0
Compressor 2 400/3/50 [A] 198.0 175.0 130.0 130.0 175.0 175.0 198.0
Compressor 3 400/3/50 [A] - 130.0 130.0 175.0 175.0 175.0 198.0
Compressor 4 400/3/50 [A] - - 130.0 130.0 175.0 175.0 198.0
External fan 400/3/50 [A] 4.7 4.7 4.7 4.7 4.7 4.7 4.7
Nr. of fans - 2 2 2 3 3 3 3
Pump 400/3/50 [A] 14.6 14.6 14.6 19.0 19.0 24.8 24.8
F.L.I. Full load power input at max admissible conditions
Compressor 1 400/3/50 [kW] 18.8 11.3 11.3 14.5 14.5 17.3 18.8
Compressor 2 400/3/50 [kW] 18.8 17.3 11.3 11.3 14.5 14.5 18.8
Compressor 3 400/3/50 [kW] - 11.3 11.3 14.5 14.5 17.3 18.8
Compressor 4 400/3/50 [kW] - - 11.3 11.3 14.5 14.5 18.8
External fan 400/3/50 [kW] 1.25 1.25 1.25 1.25 1.25 1.25 1.25
Nr. of fans - 2 2 2 3 3 3 3
Pump 400/3/50 [kW] 1.1 1.1 1.1 1.5 1.5 1.9 1.9
Total 400/3/50 [kW] 41.9 44.2 49.5 57.5 63.9 69.9 81.5
Value 400/3/50 [A] 237.7 204.4 198.4 252.2 263.8 268.8 301.4
M.I.C. Max starting current
