Control
NOTE: any of the parameters relating to the software that controls the unit can be monitored and modified. If the variables that are
accessible without requiring the password (password level "0") are insufficient,
contact the Clivet service centre, which will provide all the necessary information.
Bit = 0: No alarm - Bit = 1: Alarm present
ALARM BIT MAP 2
Bit = 0: No alarm - Bit = 1: Alarm present
ALARM BIT MAP 3
Bit no. Alarm description Reset
0 Phase monitor Manual
1 High pressure pre-alarm circuit 1 Automatic
2 High pressure pre-alarm circuit 2 Automatic
PARAMETER LOGICAL AREA (0xAA)
READ WRITE
Function Description Abbreviation Password level
HI LO
04(Read) 06(write) 0xAA 0x07 Second cooling set point SecondSetC 0
0x08 Second heating set point SecondSetH 0
0x31 Heater activation set point SetHeater 0
0x50 Set point maintenance in Cooling SetMantCool 0
0x51 Antifreeze alarm AllFreeze 0
0x52 Cooling set point SetCool 0
0x53 Heating set point SetHeat 0
0x55 Set point maintenance in Heating SetMantHeat 0
0x65 Compressor 1 hours 0
0x66 Compressor 2 hours 0
0x67 Compressor 3 hours 0
0x68 Compressor 1 starts 0
0x69 Compressor 2 starts 0
0x6A Compressor 3 starts 0
0x89 Compressor 4 starts 0
0x8A Compressor 4 hours 0
0x8B Pump 1 hours 0
0x8C Pump 2 hours 0
0x8D Maximum ventilation pre-alarm set point in
Cooling
SMaxPreC 0
Address
Bit no. Alarm description Reset
0 Inlet temperature probe fault Automatic
1 Outlet temperature probe 1 fault Automatic
2 Outlet temperature probe 2 fault Automatic
3 Coil temperature probe circuit 2 fault Automatic
4 Coil temperature probe circuit 3 fault Automatic
5 Demand Limit probe fault Automatic
6 Water Reset probe fault Automatic
7 Outside temperature transducer fault Automatic
8 Pressure probe fault circuit 2 Automatic
9 Pressure probe fault circuit 1 Automatic
10 Outside RH% probe fault Automatic
11 -
12 -
13 -
14 -
15 -
