CLIVET WSAT-YES 18.2-20.2 User Manual

37
WSAN-YES 18.2-35.2
M0ST10N19-00
USER menu - DOPPIO SETPOINT
Press ▲▼ to ENABLE or DISABLE.
Abilitare il doppio setpoint
Press ◄ ► to select the setpoint mode
Press ▲▼ to adjust the parameters
The 2nd setpoint is activated only if the “temp-switch” input on
the terminal block XT2 is closed
USER menu - TEMPERATURE COMPENSATION
Press ▲▼ to select:
COOL MODE
HEAT MODE
The water temperature is adjusted based on the outdoor temperature
T4.
COOLING
The following parameters can be adjusted:
 T4_cool_1 (25~30ºC)
 T4_cool_2 (30~40ºC)
 offset_c (0~15ºC)
HEATING
The following parameters can be adjusted:
 T4_heat_1 (0~5ºC)
 T4_heat_2 (15~20ºC)
 offset_h (0~15ºC
T4
Tws'
Tws
of f set _c
T4_cool _1
T4_cool _2
T4
Tws'
Tws
of f set _h
T4_heat _1
T4_heat _2
8 CONTROL
