General technical data
Performance
Size 18.2 20.2 25.2 30.2 35.2
Radiant panels
Heating
Heating capacity (EN 14511:2013) 1 kW 54,0 61,0 65,0 79,1 88,0
COP (EN 14511:2013) 2 4,07 4,00 4,29 4,17 4,15
ErP Space Heating Energy Class - AVERAGE
Climate - W35
9 A++ A++ A++ - -
SCOP - Average Climate - W35 8 3,93 3,91 4,08 4,07 4,06
Cooling
Cooling capacity (EN 14511:2013) 5 kW 62,1 72,3 88,5 95,1 107
EER (EN 14511:2013) 6 4,14 3,93 4,18 4,10 4,04
Water ow-rate 5 l/s 3,05 3,20 4,27 4,60 4,80
User side internal exchanger pressure drops 5 kPa 35,6 38,9 47,0 54,2 58,8
Terminal Unit
Heating
Heating capacity (EN 14511:2013) 3 kW 53,0 66,0 79,3 84,7 91,0
COP (EN 14511:2013) 2 3,21 3,17 3,33 3,29 3,25
Cooling
Cooling capacity (EN 14511:2013) 7 kW 53,3 58,9 72,0 77,7 85,0
EER (EN 14511:2013) 6 2,95 2,90 3,15 3,10 2,91
SEER 8 4,57 4,51 4,64 4,62 4,50
Water ow-rate 7 l/s 2,58 2,84 3,44 3,74 4,12
User side internal exchanger pressure drops 7 kPa 26,0 31,2 31,1 36,5 43,9
Radiators
Heating
Heating capacity (EN 14511:2013) 4 kW 54,0 63,3 78,5 85,6 92,6
COP (EN 14511:2013) 2 2,72 2,61 2,59 2,57 2,53
Water ow-rate 4 l/s 2,30 2,94 3,59 3,92 4,16
User side internal exchanger pressure drops 4 kPa 21,0 33,2 33,7 39,9 44,7
AHRI data
Cooling capacity (AHRI 550/590) 10 kW 52,6 58,3 72,3 77,8 84,6
Total power input (AHRI 550/590) 10 kW 17,1 20,1 23,0 25,2 28,9
COP
R
10 3,08 2,90 3,14 3,09 2,93
IPLV 10 4,94 4,87 4,94 4,92 4,79
The Product is compliant with the ErP (Energy Related Products) European Directive. It includes the Commission delegated Regulation (EU) No 811/2013 (rated
heat output ≤ 70 kW at specied reference conditions) and the Commission delegated Regulation (EU) No 813/2013 (rated heat output ≤ 400 kW at specied
reference conditions)
Contains uorinated greenhouse gases’(GWP 2087,5)
1. Entering/leaving water temperature user side 30/35 °C, Entering external exchanger air temperature 7 °C (R.H. = 85%)
2. COP (EN 14511:2013) Heating performance coecient. Ratio between delivered heating capacity and power input in compliance with EN 14511:2013.
3. Entering/leaving water temperature user side 40/45 °C, Entering external exchanger air temperature 7 °C (R.H. = 85%)
4. Entering/leaving water temperature user side 50/55 °C, Entering external exchanger air temperature7 °C (R.H. = 85%)
5. Entering/leaving water temperature user side 23/18 °C, Entering external exchanger air temperature 35 °C
6. EER (EN 14511:2013) cooling performance coecient. Ratio between delivered coolimg capacitu and power input in compliance with EN 14511:2013
7. User side entering/leaving water temperature 12/7 °C, external exchanger entering air 35°C
8. Data referred to unit operation with inverter frequency optimized for this application.
9. Data calculated according to the EN 14825:2016 Regulation
10. Seasonal Space Heating Energy Eciency Class according to Commission delegated Regulation (EU) No 811/2013. W = Water outlet temperature (°C)
11. Data compliant to Standard AHRI 550/590 referred to the following conditions: internal exchanger water temperature = 6,7 °C. Water ow-rate 0,043 l/s per
kW. Entering external exchanger air temperature 35°C. Evaporator fouling factor = 0.18 x 10^(-4) m2 K/W
61
