SIZE
Sound power level (dB) - Octave band (Hz)
Sound
power
level
Sound
pressure
level
63 125 250 500 1000 2000 4000 8000
dB(A) dB(A)
90.3 73 74 81 84 86 85 78 68 71 90
110.4 74 76 83 86 87 86 79 69 72 91
130.4 74 75 83 86 87 87 79 69 73 92
145.5 75 76 83 87 89 88 80 70 73 93
170.5 73 74 80 87 90 90 81 70 74 94
185.5 73 74 80 87 90 90 81 69 74 94
210.6 74 75 81 88 91 91 82 71 75 95
225.6 75 76 82 89 92 92 83 71 76 96
240.6 75 75 81 89 92 91 83 71 76 96
Sound levels - Premium
Sound levels refer to full load units, in test nominal conditions. The sound pressure level refers to 1 m. from the standard unit outer surface operating in open field. Measures accor-
ding to UNI EN ISO 9614-2 regulations, with respect to the EUROVENT 8/1 certification, which provides for a tolerance of 3 dB(A).
Data referred to the following conditions:
- internal exchanger water temperature = 12/7 °C
- ambient temperature = 35 °C
Standard acoustic configuration (ST)
Acoustic configuration with compressor soundproofing (SC)
SIZE
Sound power level (dB) - Octave band (Hz)
Sound
power
level
Sound
pressure
level
63 125 250 500 1000 2000 4000 8000
dB(A) dB(A)
90.3 71 72 77 83 83 82 74 65 68 87
110.4 72 74 79 84 84 83 76 66 69 88
130.4 72 73 79 84 85 84 76 66 70 89
145.5 72 73 79 84 85 84 76 66 69 89
170.5 71 72 77 85 87 85 77 66 70 90
185.5 71 72 77 85 87 85 78 66 70 90
210.6 72 73 78 86 88 86 78 67 71 91
225.6 73 74 79 87 89 87 79 68 72 92
240.6 73 74 79 86 89 87 79 67 72 92
Sound levels refer to full load units, in test nominal conditions. The sound pressure level refers to 1 m. from the standard unit outer surface operating in open field. Measures accor-
ding to UNI EN ISO 9614-2 regulations, with respect to the EUROVENT 8/1 certification, which provides for a tolerance of 3 dB(A).
Data referred to the following conditions:
- internal exchanger water temperature = 12/7 °C
- ambient temperature = 35 °C
