CLIVET WSAT-YSC4 User Manual

General technical data
SIZE 80.3 100.4 115.4 130.4 155.5 170.5 185.5 210.6 225.6 240.6
Cooling capacity 1 [kW] 223 267 315 364 424 472 520 574 624 676
Compressor power input 1 [kW] 64,3 80,3 93,2 107 125 139 156 171 186 204
Total power input 2 [kW] 68,9 84,8 98,9 114 133 148 165 182 198 215
Partial recovery heating capacity 3 [kW] 58,3 70,5 82,8 95,8 112 124 137 151 165 179
Total recovery heating capacity 3 [kW] 262 317 373 431 502 559 618 681 741 804
EER 1 - 3,23 3,15 3,18 3,20 3,18 3,19 3,15 3,16 3,16 3,14
Water flow-rate (User Side) 1 [l/s] 10,6 12,8 15,0 17,4 20,2 22,6 24,8 27,4 29,8 32,3
Internal exchanger pressure drops 1 [kPa] 20 27 30 37 41 38 39 46 50 41
Cooling capacity (EN14511:2018) 4 [kW] 222 267 314 364 423 472 520 573 624 675
Total power input (EN14511:2018) 4 [kW] 69,4 85,5 100
115 135 149 167 184 200 218
EER (EN14511:2018) 4 - 3,20 3,12 3,15 3,17 3,15 3,16 3,11 3,12 3,12 3,10
SEER 6 - 4,70 4,67 4,78 4,75 4,92 5,00 4,96 4,94 4,96 4,90
SEPR 7 - 6,44 6,40 6,55 6,51 6,54 6,65 6,60 6,57 6,60 6,52
Cooling capacity (AHRI 550/590) 5 [kW] 221 265 312 361 420 468 514 568 622 671
Total power input (AHRI 550/590) 5
[kW]
68,7 84,5 98,5 113 133 147 165 181 197 215
COP
R
5
-
3,22 3,14 3,17 3,19 3,16 3,18 3,12 3,14 3,16 3,12
IPLV 5
-
5,05 4,93 4,85 4,82 4,85 4,93 4,88 4,87 4,84 4,82
The Product is compliant with the Erp (Energy Related Products) European Directive. It includes the Commission delegated Regulation (EU) No 2016/2281, also known as Ecodesign LOT21.
Contains fluorinated greenhouse gases (GWP 675)
1. Data referred to the following conditions: internal exchanger water temperature = 12/7 °C. Entering external exchanger air temperature = 35°C. Evaporator fouling factor = 0.44 x
10^(-4) m2 K/W.
2. The Total Power Input value does not take into account the part related to the pumps and required to overcome the pressure drops for the circulation of the solution inside the exchangers.
3. Recovery exchanger water = 40/45°C
4. Data compliant to Standard EN 14511:2018 referred to the following conditions: internal exchanger water temperature = 12/7 °C. Entering external exchanger air temperature = 35°C
5. Data compliant to Standard AHRI 550/590 referred to the following conditions: internal exchanger water temperature = 6,7 °C. Water flow-rate 0,043 l/s per kW. Entering external exchanger air
temperature = 35°C. Evaporator fouling factor = 0.18 x 10^(-4) m2 K/W
6. Data compliant to Standard EN 14825:2018
7. Data compliant according to EU regulation 2016/2281
Standard acoustic configuration (ST) / Compressor soundproofing (SC)
SIZE 80.3 100.4 115.4 130.4 155.5 170.5 185.5 210.6 225.6 240.6
Cooling capacity
1
[kW] 217 262 306 355 409 459 504 556 599 646
Compressor power input
1
[kW] 67,5 85,7 98,4 113 130 147 165 183 197 217
Total power input
2
[kW] 70,1 88,2 102 116 134 152 171 189 203 224
Partial recovery heating capacity 3 [kW] 57,4 70,0 81,6 94,4 109 122 135 149 161 174
Total recovery heating capacity 3 [kW] 258 315 367 425 489 551 608 672 724 784
EER 1 - 3,10 2,97 3,01 3,04 3,04 3,02 2,96 2,95 2,95 2,89
Water flow-rate (User Side)
1
[l/s] 10,4 12,5 14,6 16,9 19,5 21,9 24,1 26,6 28,6 30,8
Internal exchanger pressure drops
1
[kPa] 19 26 29 34 39 37 37 44 47 38
Cooling capacity (EN14511:2018)
4
[kW] 217 261 306 354 408 459 504 556 599 645
Total power input (EN14511:2018) 4 [kW] 70,5 88,9 102
118 136 153 172 191 205 225
EER (EN14511:2018) 4 - 3,07 2,94 2,98 3,01 3,01 2,99 2,93 2,91 2,92 2,86
SEER
6
- 4,66 4,62 4,73 4,70 4,87 4,94 4,91 4,89 4,91 4,79
SEPR 7 - 6,38 6,33 6,48 6,44 6,48 6,57 6,53 6,50 6,53 6,46
Cooling capacity (AHRI 550/590)
5
[kW] 215 259 303 351 405 455 499 551 597 643
Total power input (AHRI 550/590)
5
[kW]
69,8 87,8 101 116 134 151 170 188 203 223
COP
R
5
-
3,08 2,95 3,00 3,03 3,02 3,01 2,94 2,93 2,94 2,88
IPLV 5
-
5,01 4,86 4,79 4,75 4,80 4,78 4,87 4,85 4,83 4,80
The Product is compliant with the Erp (Energy Related Products) European Directive. It includes the Commission delegated Regulation (EU) No 2016/2281, also known as Ecodesign LOT21.
Contains fluorinated greenhouse gases (GWP 675)
1. Data referred to the following conditions: internal exchanger water temperature = 12/7 °C. Entering external exchanger air temperature = 35°C. Evaporator fouling factor = 0.44 x
10^(-4) m2 K/W.
2. The Total Power Input value does not take into account the part related to the pumps and required to overcome the pressure drops for the circulation of the solution inside the exchangers.
3. Recovery exchanger water = 40/45°C
4. Data compliant to Standard EN 14511:2018 referred to the following conditions: internal exchanger water temperature = 12/7 °C. Entering external exchanger air temperature = 35°C
5. Data compliant to Standard AHRI 550/590 referred to the following conditions: internal exchanger water temperature = 6,7 °C. Water flow-rate 0,043 l/s per kW. Entering external exchanger air
temperature = 35°C. Evaporator fouling factor = 0.18 x 10^(-4) m2 K/W
6. Data compliant to Standard EN 14825:2018
7. Data compliant according to EU regulation 2016/2281
Super-silenced acoustic configuration (EN)
Performance - Excellence
61
