Page #62 background imageLoading...
Page #62 background image
SIZE 90.3 110.4 130.4 145.4 170.5 185.5 210.6 225.6 240.6
Cooling capacity 1 [kW] 232 291 333 385 444 484 538 591 644
Compressor power input
1
[kW] 80,5 96,6 118 131 148 171 189 198 222
Total power input
2
[kW] 83,9 101 123 137 155 177 197 207 231
Partial recovery heating capacity 3 [kW] 63,2 78,6 91,3 105 120 132 147 160 175
Total recovery heating capacity 3 [kW] 284 354 411 471 540 596 662 720 789
EER 1 - 2,76 2,88 2,72 2,80 2,87 2,73 2,73 2,85 2,79
Water flow-rate (User Side)
1
[l/s] 11,1 13,9 15,9 18,4 21,2 23,1 25,7 28,2 30,8
Internal exchanger pressure drops 1 [kPa] 21 32 34 42 44 40 48 49 51
Cooling capacity (EN14511:2018)
4
[kW] 232 291 333 384 443 483 537 590 644
Total power input (EN14511:2018) 4 [kW] 84,5 102 124 139 156 179 199 209 233
EER (EN14511:2018) 4 - 2,74
2,85 2,70 2,77 2,84 2,70 2,70 2,82 2,76
SEER
6
- 4,38 4,48 4,46 4,47 4,65 4,64 4,61 4,69 4,62
SEPR 7 - 6,00 6,13 6,11 6,13 6,18 6,17 6,13 6,23 6,15
Cooling capacity (AHRI 550/590)
5
[kW] 230 288 330 381 440 479 532 585 637
Total power input (AHRI 550/590)
5
[kW]
83,6 101 122 137 154 177 196 206 230
COP
R
5
-
2,75 2,85 2,70 2,78 2,86 2,71 2,71 2,84 2,77
IPLV 5
-
4,59 4,79 4,64 4,67 4,65 4,73 4,59 4,57 4,55
The Product is compliant with the Erp (Energy Related Products) European Directive. It includes the Commission delegated Regulation (EU) No 2016/2281, also known as Ecodesign LOT21.
Contains fluorinated greenhouse gases (GWP 675)
1. Data referred to the following conditions: internal exchanger water temperature = 12/7 °C. Entering external exchanger air temperature = 35°C. Evaporator fouling factor = 0.44 x
10^(-4) m2 K/W.
2. The Total Power Input value does not take into account the part related to the pumps and required to overcome the pressure drops for the circulation of the solution inside the exchangers.
3. Recovery exchanger water = 40/45°C
4. Data compliant to Standard EN 14511:2018 referred to the following conditions: internal exchanger water temperature = 12/7 °C. Entering external exchanger air temperature = 35°C
5. Data compliant to Standard AHRI 550/590 referred to the following conditions: internal exchanger water temperature = 6,7 °C. Water flow-rate 0,043 l/s per kW. Entering external exchanger air
temperature = 35°C. Evaporator fouling factor = 0.18 x 10^(-4) m2 K/W
6. Data compliant to Standard EN 14825:2018
7. Data compliant according to EU regulation 2016/2281
SIZE 90.3 110.4 130.4 145.4 170.5 185.5 210.6 225.6 240.6
Cooling capacity
1
[kW] 228 283 329 374 432 474 527 580 623
Compressor power input
1
[kW] 83,3 99,6 124 135 153 178 196 205 230
Total power input
2
[kW] 85,8 103 127 139 158 183 202 211 236
Partial recovery heating capacity 3 [kW] 62,7 77,4 91,4 103 118 132 146 159 172
Total recovery heating capacity 3 [kW] 282 348 411 462 532 592 657 714 775
EER 1 - 2,65 2,75 2,59 2,69 2,74 2,59 2,62 2,75 2,64
Water flow-rate (User Side)
1
[l/s] 10,9 13,5 15,7 17,8 20,6 22,6 25,2 27,7 29,7
Internal exchanger pressure drops
1
[kPa] 21 30 33 39 42 39 46 47 48
Cooling capacity (EN14511:2018)
4
[kW] 227 283 329 374 432 474 527 580 622
Total power input (EN14511:2018) 4 [kW] 86,3 104 128 140 159 184 203 213 239
EER (EN14511:2018) 4 - 2,63
2,73 2,57 2,67 2,71 2,57 2,59 2,72 2,61
SEER
6
- 4,34 4,44 4,42 4,45 4,62 4,61 4,59 4,63 4,59
SEPR 7 - 5,95 6,08 6,06 6,10 6,14 6,13 6,10 6,16 6,10
Cooling capacity (AHRI 550/590)
5
[kW] 226 281 326 370 429 470 522 574 616
Total power input (AHRI 550/590)
5
[kW]
85,4 103 126 138 157 182 201 210 235
COP
R
5
-
2,65 2,73 2,59 2,68 2,73 2,58 2,60 2,73 2,62
IPLV
5
-
4,54 4,74 4,62 4,67 4,62 4,50 4,57 4,56 4,51
The Product is compliant with the Erp (Energy Related Products) European Directive. It includes the Commission delegated Regulation (EU) No 2016/2281, also known as Ecodesign LOT21.
Contains fluorinated greenhouse gases (GWP 675)
1. Data referred to the following conditions: internal exchanger water temperature = 12/7 °C. Entering external exchanger air temperature = 35°C. Evaporator fouling factor = 0.44 x
10^(-4) m2 K/W.
2. The Total Power Input value does not take into account the part related to the pumps and required to overcome the pressure drops for the circulation of the solution inside the exchangers.
3. Recovery exchanger water = 40/45°C
4. Data compliant to Standard EN 14511:2018 referred to the following conditions: internal exchanger water temperature = 12/7 °C. Entering external exchanger air temperature = 35°C
5. Data compliant to Standard AHRI 550/590 referred to the following conditions: internal exchanger water temperature = 6,7 °C. Water flow-rate 0,043 l/s per kW. Entering external exchanger air
temperature = 35°C. Evaporator fouling factor = 0.18 x 10^(-4) m2 K/W
6. Data compliant to Standard EN 14825:2018
7. Data compliant according to EU regulation 2016/2281
Super-silenced acoustic configuration (EN)
Performance - Premium
Standard acoustic configuration (ST) / Compressor soundproofing (SC)
62
