CLIVET WSAT-YSC4 User Manual

Excellence
SIZE 80.3 100.4 115.4 130.4 155.5 170.5 185.5 210.6 225.6 240.6
Compressor
Type of compressors 1 SCROLL
Refrigerant R-32
No. of compressors Nr 3 4 4 4 5 5 5 6 6 6
Rated power (C1) HP 40 50 50 50 50 65 80 105 105 120
Rated power (C2) HP 40 50 65 80 105 105 105 105 120 120
Std Capacity control steps 4 4 6 4 6 7 6 8 8 6
Oil charge (C1) l 8 9 9 9 9 11 13 17 17 23
Oil charge(C2) l 6 9 11 13 17 17 17 17 23 23
Refrigerant charge (C1) kg 17 17 19 20 21 26 27 30 30 31
Refrigerant charge (C2) kg 16 16 19 23 30 27 28 31 36 38
Refrigeration circuits Nr 2 2 2 2 2 2 2 2 2 2
Internal exchanger (evaporator)
Type of internal exchanger 2 PHE
N. of internal exchanger Nr 1 1 1 1
1 1 1 1 1 1
Water content l 20 20 24 28 36 48 57 57 49 60
Minimum system water content l 1350 2700 2700 2200 3200 2850 3150 3450 3750 4500
External exchanger (condenser)
Type of external exchanger 3 CCM
Number of coils Nr 4 4 5 6 7 8 8 9 10 10
External Section Fans
Type of fans 4 AX
Number of fans Nr 4 4 5 6 7 8 8 9 10 10
Type of motor 5 EC
Standard airflow (ST/SC) l/s 21778 21778 27222 32667 38111 43556 43556 49000 54444 54444
Standard airflow (EN) l/s 16111 16111 20139 24167 28194 32222 32222 36250 40278 40278
Connections
Water fittings 4" 4" 4" 4" 5" 5" 5" 5" 5" 5"
Power supply
Standard power supply 400/3~/50
Electrical data
F.L.A. - Total A 158,2 191,0 220,8 250,6 298,3 328,1 356,0 403,7 433,5 461,4
F.L.I. - Total kW 96,3 115,4 135,1 154,7 183,6 203,2 221,6 250,5 270,1 288,5
M.I.C. - Value 6 A 492,5 432,7
555,1 584,9 632,6 662,4 690,3 738,0 767,8 795,7
M.I.C. - with soft start accessory 6 A 314,5 301,2 377,1 406,9 454,6 484,4 512,3 560,0 589,8 617,7
Construction
1. ISW = Double screw compressor
2. S&T = Shell and tube
3. CCM = Full aluminium microchannel coils
4. AX = Axial fan
5. EC = Asynchronous motor with permanent magnet commuted electronically.
6. M.I.C.=Maximum unit starting current. The M.I.C. value is obtained adding the max. compressor starting current of the highest size to the power input at max. admissible condi-
tions (F.L.A.) of the remaining electric components.
Unbalance between phase max 2 %
Voltage variation: max +/- 10%
Electrical data refer to standard units; according to the installed accessories, the data can suer some variations.
