©Ecoflo Wastewater Management Pty LtdIMCM-203-2023.08.30
5
If there is a joist in the way, either reposition the waste hole OR install trimmer joists to each end
of the cut joist, and fix all connections with galvanized framing anchors with 4 nails each leg
(refer to diagram below).
View from under floor
2
Following the pedestal floor template, draw a 240mm diameter circle. Cut out the hole with
a jigsaw.
