7.1 – Crestron
Simple Windows Name: Clock_Audio_CDT100_Module
Summary:
This module provides control and feedback of the Clockaudio CDT100 via UDP. It also provides true feedback.
General Notes:
 Pulse the Inialize input before performing any other operaons.
 The module ulizes a “Heartbeat” to maintain communicaon with the CDT100. This heartbeat will begin once preliminary
inializaon is complete.
 Should a heartbeat response not be received, the module will aempt to send the heartbeat two more mes in succession.
 If neither of these responses are received, the module will consider communicaon with the CDT100 to be broken, it will clear
all exisng data and output signals, and will aempt to re-establish communicaon with the CDT100 every 10 seconds.
 Once communicaon has been re-established, the module will automacally re-inialize.
 The module will automacally subscribe for available unsolicited feedback with the CDT100 upon inializaon.
Crestron Hardware Required: 3 Series Compable only
Setup of Crestron Hardware:
 Connect Crestron 3-series processor via Ethernet port of same network that CDT100 is on.
 Congure IP address of both Crestron and CDT100. (Ensure subnet sengs match).
Vendor Firmware: 99.5
OPS Used for Tesng: RMC3 (1.010.0060)
Sample Program: Clock_Audio_CDT100_Demo
Download the Crestron interface module and applicaon notes from the CDT100 product / Technical Downloads secon of the
website www.clockaudio.com.
© Clockaudio 2015
