7.2 – AMX

To interface to the AMX Clock Audio CDT100 module, the programmer must perform the following steps:

 Dene the device ID for the CDT100 that will be controlled.

 Dene the NetLinx virtual device ID that the CDT100 COMM module will use to communicate with the main program and User

Interface.

If a touch panel interface is desired, demo programs have been created for tesng.

Touch Panel le - Clock Audio-CDT100_Demo_Panel.tp4

Demo program (ClockAudio_CDT100_Demo.axs

(Go to www.clockaudio.com CDT100 Technical Downloads).

The CDT100 module must be included in the program with a DEFINE_MODULE command. This command starts execuon of the

module and passes in the following key informaon: the device ID of the CDT100, and the virtual device ID for communicang to

the main program.

 Issue the following SEND_COMMAND’s to the virtual device in the virtual device ONLINE event:

 PROPERTY-IP_ADDRESS,<IP Address of the CDT100>

 PROPERTY_IP_PORT,<UDP Port used to communicate with the CDT100>

 REINIT

An example of how to do this is shown below.

DEFINE_DEVICE

dvCDT100 = 0:3:0

vdvCDT100 = 33001:1:0

dvTP_CH32_In = 10003:1:0

dvTP_CH32_Out = 10003:2:0

dvTP Arm_C = 10003:3:0

dvTP_Phantom = 10003:4:0

dvTP_Preset = 10003:5:0

DEFINE_MODULE 'ClockAudio_CDT100_Module' ClockAudioCDT100 (vdvCDT100, dvCDT100)

DATA_EVENT [vdvCDT100]

ONLINE:

SEND_COMMAND vdvCDT100,"PROPERTY-IP_ADDRESS,192.168.187.219"

SEND_COMMAND vdvCDT100,"PROPERTY-IP_PORT,49494"

SEND_COMMAND vdvCDT100,"REINIT"

Upon re-inializaon the AMX Comm module will communicate with the CDT100 and informaon will be exchanged.

Port Mapping

This module uses mulple virtual device ports in order disnguish events for one channel on the CDT100 from another

(i.e. virtual device port 1 = Channel 1, virtual device port 2 = Channel 2, etc.)

Virtual Device Buon Events Channels Levels Control Feedback

33001:1:0 – 33001:4:0 1 1, 2, 3, 4, 5, 6, 251, 252 None See tables See tables

CDT100 User Manual

Download the AMX interface module and applicaon notes from the CDT100 product / Technical Downloads secon of the

website www.clockaudio.com.
