8 – Consultants Specicaons
The Dante interface unit shall provide four mic analog inputs on the rear panel via 3-pin de-pluggable connectors.
Each of the four inputs will have unity gain and a +48V phantom power opon shall be provided via soware for each input.
The unit shall provide two RJ-45 network connectors to allow Dante Daisy Chaining (DDC) of mulple units.
The internal analog to digital signal conversion shall be performed at 24-bit resoluon with a sampling frequency of 48kHz.
The Dante interface unit shall receive power from an external +12V supply.
Four control ports will be available for interfacing with switch buons and dual color LED.
An interface for motorized microphones shall be included.
The Dante interface unit shall be compable with third party control systems for exible control and monitoring in system
applicaons.
The Dante interface shall be compable with Clockaudio CH32 and other Clockaudio control devices.
The Dante interface shall be compliant with the RoHS direcve.
The Dante interface unit shall be compliant with the EMI/EMC requirements for FCC and CE.
The Dante interface unit shall be the Clockaudio CDT100.
Audio Inputs
Input Type: Balanced and RF ltered
Gain: 0dB
Input Impedance: >1.8K ohms at any gain
Phantom Power: +48V, soware selectable
Audio Performance:
EIN: -115dBu
System THD+N: <0.01% at any gain, input signal 3dB
below maximum
Frequency Response 20Hz – 20kHz, +/- 1dB
CH32 Control Device Inputs
RJ-45 Buon and Dual color LED
ARM Interface
RJ-12
Dante Network
Physical Level: Standard Ethernet
Connector: RJ-45
Cable Quality: CAT 5, CAT 6
Transmission Speed: 100 Mbps
Power Requirements +12V DC
Power Consumpon 4.9W Max
Dimensions 8.32” W x 1.50” H x 4.74” D
Weight 1.75 lbs
Compliance FCC CFR 47 Parts 15B ICES-003
CE (EN55022) RoHS
