Club Car Precedent Villager 2 User Manual

19
KeySwitch
GASOLINEVEHICLE-ELECTRICAL
COMPONENTS
KEYSWITCH
SeeGeneralWarningsonpage1-2.
TESTINGTHEKEYSWITCH
SeeTestProcedure5–KeySwitch(StartCircuit)onpage18-19.
SeeTestProcedure6–KeySwitch(EngineKillCircuit)onpage18-19.
KEYSWITCHREMOVAL
1.Disconnectbatteryandsparkplugwire(s).
SeeDisconnectingtheBattery-GasolineVehiclesonpage1-3.
2.Removetheinstrumentpanel.
2.1.Removethreescrews(1)fromtheinstrumentpanel(2)(Figure19-19,Page19-18).
2.2.Rotatetheinstrumentpanelupandawayfromthedashtodisengagethetabsatthetopoftheinstrument
panel.
2.3.Disconnecttheelectricalconnector(3)totheinstrumentpanel.
2
1
1
3
4
9
6
8
2433
Figure19-19InstrumentPanelRemoval
703
Figure19-20KeySwitch
3.Disconnectthewiresfromthekeyswitch.
4.Fromthebackoftheinstrumentpanel,pushdownontheretainingtabssurroundingthekeyswitch(4)and
removethekeyswitchcap(8).Holdthekeyswitchandremovetheswitchretainingnut(6)fromtheoutsideof
theinstrumentpanel(Figure19-20,Page19-18).
Page19-182019PrecedentVillager2MaintenanceandServiceManual
